New Progressive /brooks Automation Sentry 1510 Furnace Pressure Control System

US $9914

Phoenix, Arizona, United States
Jun 18th

Open on mobile:
QR code

NEW Brooks Automation / Progressive Technologies SENTRY 1510 Automated Process Pressure Control System Comes with a manual and what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from Progressive/Brooks and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This unit is new, old stock from ASM. The Unit's Serial Number Tag Reads: Product Type: S1510 Manual Model Number: Prototype Serial Number: 11554 Link to the Datasheet: Brooks Automation SENTRY 1510 Presure Control System Datasheet General Description: The SENTRY 1510 controls pressure in atmospheric diffusion furnaces and other atmospheric process chambers improving process repeatability and reducing contamination. Through its rapid response to fluctuations, the production-proven SENTRY 1510 prevents backstreaming of contamination from house exhaust and provides a stable process environment even with widely fluctuating house exhaust or gas flows. The sealed system contains HCl fumes, improving worker safety. Features: Sealed system Air-flow regulation with millisecond response time Automatic set point control Analog or digital host communication Production-proven Benefits: For Diffusion/Oxidation: Enables thinner oxide control Controls contamination protection from backstreaming Improves process repeatability Saves energy Primary Applications: Diffusion Oxidation Specifications: Negative Pressure Configuration: -0.12" to -1.85" of water column. (-3 mm to -47 mm to water column.) Positive Pressure Configuration: +0.12" to +1.85" of water column. (+3 mm to +47 mm of water column.) Flow Range: 0.01 to 1.05 SCFM (0.3 to 30 LPM) Accuracy to Set Point: ±0.04" of water column. (±1.0 mm of water column.) for dry process, ±0.08" of water column. (±2.0 mm of water column.) for pyrogenic processes Response Time: 50 milliseconds to exhaust fluctuations of 100%. Response to pyrogenic ignition or extinguish will vary by installation. Materials: Ryton and Teflon with Viton elastomers Set Point Control: 0-5 volt analog, RS422/RS485 at 9600 baud, Stand alone operator keypad Power Requirements: TIM (Supervisor): +15 to +24 VDC, 650 mA and -15 to -24 VDC, 50 mA Power Supply: 90 - 260 VAC, 47-63 Hz, 12 W nominal Facilities Requirements: Minimum House Exhaust: Negative pressure configuration 0.4" w.c. (10 mm w.c.) more negative than set point, Positive pressure configuration -0.5" w.c. (-13 mm w.c.) Maximum House Exhaust: 5.0" of water column (125 mm of water column.) Nitrogen: Input Tube OD: .25" Minimum Pressure: 40 psig (2.8 Kg/cm2) Maximum Pressure: 100 psig (7.0 Kg/cm2) Minimum Grade: House grade or better Input and Output Connections: 1" female NPT Dimensions: Sentry 1510 Valve: 6.0" L x 3.0" W x 8.5" H (152 mm x 76 mm x 216 mm) TIM Module: 8.25" L x 2.38" W x 5.25" H (209 mm x 60 mm x 133 mm) Weight: Sentry 1510 Valve: 7 lbs. (3.2 kg) TIM Module: 2 lbs. (0.9 kg) For More Pictures Please Click the Following: Picture 2 - Side View #1 Picture 3 - Side View #2 Picture 4 - Side View #3 Picture 5 - Side View #4 Picture 6 - Serial Number Tag For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $15.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I need to know the following information: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 01/04/13 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
