New Quality Cnc 200khz 6 Axis Usb Card Mach3 Breakout Interface Controller Board

US $160.98

Changzhou,Jiangsu, China
Jan 29th

Open on mobile:
QR code

Package include: 1 x 6 axis 200Khz USB MACH3 breakout board 1 x USB Cable 1 x CD (CD include with English user manual and software and dll file) 1. Products brief introduction DDSMXV5.0 is designed by our Studio,it is a CNC system based mach3.It’s version is 5.0 now.You do not need to add other Hardware,and you can complete the signal conversion from the G-code to the movement of the stepper motor drive control. This card is compatible with most stepper drives and servo drives. And it is perfect weapon to replace mach3 parallel interface board. DDSMXV5.0 include DDSM3V5.0,DDSM4V5.0,DDSM5V5.0 DDSM6V5.0,they are 3/4/5/6 axes mach3 CNC card. These 4 cards use the same Hardware platformDDSMXV5.0.They are limited to 3/4/5/6 axes for different voice of customer .They use the same manual. 2. Computer system requirement Basic Configuration: 1) CPU: 1GHz; 2) Memory: 512MB 3) 500MB Available disk space 4) USB 2.0 Recommended configuration: 1) CPU: 2GHz Dual Core; 2) Memory: 2GB; 3) 1G Available disk space 4) USB 2.0 3.Production appearance and size 1) USB communication interface, and power supply for the board 2) 10 IO input, opto-isolated,It Can be configured to limit the emergency stop and other functions,all of them are 2edg port. 3) 14 IO input with no opto-isolated but with iso-IC. This port is set to IDC 2.54mm port. 4) 14 IO output with no opto-isolated but with iso-IC. This port is set to IDC 2.54mm port. 5) 2IO output with opto-isolated for spindle. 6) up to 6 axes stepper-motor control port. Each port has up to 200KHz plus output 7) COTEX-M3 of NXP-LPC is main control chip New feature 8) New design Aluminum shell make the system more stable 9) This system is equipped with RS2332 manual control box. You can use manual control box with this port. 10) Spindle control port has PWM Mod( 0% - 100% dutycycle with 12Vpp)and voltage Mod(0-10V) 11) Spindle speed feed back port-INDEX. 12) There is a power autostability system. When USB port overvoltage or undervoltage or within other EMI, this system can make power of system stable. 13) There are High speed interface chips,which make stepper driver signal more stable. 14) There is a USB protection chip,which can protect system within high voltage EMI 4.Detailed functional introduction A System input voltage 5V B. Operating voltage of input interface with no opto-isolated:5V C Operating voltage of input interface with opto-isolated:12V D Operating voltage of output interface:5V E stepper motor control signal output voltage:5V F Spindle Signal: 10V Shipping Please open the package and check if there are some damages before sign, if there are some damages , please do not sign and contact us immediately We ship to worldwide When you buy 1-2pcs we usually ship by Hongkong/China Air Post which will take round 10-15 business days. some areas may be later due to variation of postal service in different areas,if above 3pcs we can ship by DHL/UPS/EMS which need confirm by us All items will be shipped within 1-3 business days upon receipt of payment Payment We accept paypal payment,all Paypal must be confirmed(shipping and billing address must match and correct and it need tell us your telephone no for delivery) Payment must be made within 48hours of the auction end time Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer responsibility. Refund When you have the parcel,and not satisfied the goods or it is other problem like as broken,pls tell us the detail reason and provide the photos. Any reason required for all refund. Item must be in it's original condition and no physical damage. Buyer responsible for all shipping cost. Contact us Welcome worldwide customer inquire and questions,we will try to do our best to feedback customer's email within 1-2 business days,if not pls check the mail box again. Customer's satisfaction is very important to us.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	RATTM MOTOR
Port	USB Mach3 port
Model	USB MACH3 DDSM6V5.0
Size	120x70x20mm
Country/Region of Manufacture	China
Computer system	Win XP/2000/7/8
Item	6 axis USB Mach3 controller
Frenquence	200KHz
Color	Blue
Axis	4 Axis
Weight	0.25kgs
Place of Origin	Jiangsu, China (Mainland)
