New Securitron Magnalock Aqd6-8f8r Proprietary Psu 6a 12/24vdc 8 Fused Outputs

US $240

Willoughby, Ohio, United States
Nov 18th

Open on mobile:
QR code

Securitron AQD6-8F8R Proprietary Power Supply - Power Supply 6A, 12/24VDC, 8 Fused Outputs, Relays, FT 120 V AC, 230 V AC Input Voltage 12 V DC, 24 V DC Output Voltage External 90% Efficiency Power supply 6A 12/24 VDC P/N: AQD6-8F8R Manufacturer: Securitron Magnalock Corporation UPC: 784607043386 The AQD6 are heavy duty self contained, efficient, clean, off-line switching power supplies with linear type performance that is jumper selectable between 12vdc at 6 Amps, and 24vdc at 6 Amps. Both have a dedicated lead acid battery(s) charger that obtains maximum battery life while providing a 12vdc or 24vdc uninterruptible power supply for access control security systems. The field select able AC input allows these power supplies to be powered anywhere in the world. The AQD6 has exceptional brown out capability with operation down to 85% of nominal voltage. The AQD6 has an extensive filtering system that provides linear output performance. The AQD6 is electronically protected against Battery reversal, shorting or overloading. Power Limited Output with Thermal Protection when in models AQD6-8F, AQD6-8C, AQD6-16F, AQD6-16C, AQD6-8F8R, and AQD6-8C1R. Non power limited when model AQD6. Each of these protective features will self-restore. Before connecting load and battery(s), move the 12v/24v jumper to desired voltage. Caution, damage can occur when switched with DC output load. Confirm proper voltage before connecting devices. The AQD6 is UL Listed and has the additional supervisory features of a battery disconnect relay when battery(s) are depleted, a set of form "C" relay contacts that indicates AC power failure, a set of form "C" relay contacts to indicate low battery(s) and the DC Output is Class II power limited. Depending on load, low battery trouble indicates 50-75% battery capacity remaining. Input wiring to the unit should be enclosed in conduit secured firmly to the enclosure. The AQD6 cannot be used to power a mercantile bell. The AQD6 are heavy duty self contained, efficient, clean, off-line switching power supplies with linear type performance that is jumper selectable between 12vdc at 6 Amps, and 24vdc at 6 Amps. Both have a dedicated lead acid battery(s) charger that obtains maximum battery life while providing a 12vdc or 24vdc uninterruptible power supply for access control security systems. The field select able AC input allows these power supplies to be powered anywhere in the world. The AQD6 has exceptional brown out capability with operation down to 85% of nominal voltage. The AQD6 has an extensive filtering system that provides linear output performance. The AQD6 is electronically protected against Battery reversal, shorting or overloading. Power Limited Output with Thermal Protection when in models AQD6-8F, AQD6-8C, AQD6-16F, AQD6-16C, AQD6-8F8R, and AQD6-8C1R. Non power limited when model AQD6. Each of these protective features will self-restore. Before connecting load and battery(s), move the 12v/24v jumper to desired voltage. Caution, damage can occur when switched with DC output load. Confirm proper voltage before connecting devices. The AQD6 is UL Listed and has the additional supervisory features of a battery disconnect relay when battery(s) are depleted, a set of form "C" relay contacts that indicates AC power failure, a set of form "C" relay contacts to indicate low battery(s) and the DC Output is Class II power limited. Depending on load, low battery trouble indicates 50-75% battery capacity remaining. Input wiring to the unit should be enclosed in conduit secured firmly to the enclosure. The AQD6 cannot be used to power a mercantile bell. Technical Information Efficiency: 90% Power Description Input Voltage: 120 V AC, 230 V AC Output Voltage: 12 V DC 6 A, 24 V DC 6 A Physical Characteristics Form Factor: External Height: 14" Width: 14" Depth: 4.8" Weight (Approximate): 9.65 lb Technical Information Efficiency: 90% Power Description Input Voltage: 120 V AC, 230 V AC Output Voltage: 12 V DC 6 A, 24 V DC 6 A Physical Characteristics Form Factor: External Height: 14" Width: 14" Depth: 4.8" Weight (Approximate): 9.65 lb Item weight: 12lb Dimensional shipping weight: N/Alb 784607043386 AQD68F8R Terms and Conditions Domestic orders are shipped within 2 business days from payment processing. Please be aware that your order may be processed on the following business day after you check out. All domestic shipping is via UPS or Fedex Ground service. Please contact us for Overnight and Second Day Air shipping before you place your order. International buyers: You are purchasing a product designed for use in North America. The power and transmission requirements may be different then in your local country, please make sure to follow all applicable use and safety regulations. Shipments for international export, PO Boxes, Puerto Rico, US protectorates, military addresses, and Canada require an additional 3-4 business days of processing time before shipment. International and Postal Shipments: Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the recipient's responsibility. Please check with your country s customs office to determine what these additional costs will be prior to bidding/buying. These charges are normally collected by the delivering freight (shipping) company or when you pick the item up. Please do not confuse them for additional shipping charges. We do not mark merchandise values below value or mark items as "gifts" because US and International government regulations prohibit such behavior. International orders are shipped via FedEx and UPS except for Canada (UPS), and parts of Europe/Russia (USPS EMS). Shipments to PO boxes, military, and US addresses outside the contiguous 48 states may be sent via USPS. Heavy or over-size items which mus be shipped USPS may incur additional shipping charges or be rejected by the post office. Not all addresses are serviced by our shippers, additional charges may be required for delivery to some locations. Please contact us before placing your order if you require combined shipping for multiple different items. Returns, Refunds, and Cancellations We stand by the items we sell and will issue a full refund including freight charges on any defective or ship damaged item. Please inspect your item as soon as it arrives, we only accept reports of shipping damage within 14 days from delivery We also understand that our customers may change their mind after purchasing a product. We will accept returns on these orders, although the shipping charges and a restocking fee will be withheld from your refund. A return number is required for all returned shipments to guarantee that you return is processed as quickly as possible. All returns must be shipped to the appropriate facility for processing. Before returning a product, please contact us to receive return instructions. Items must be returned within 30 days from purchase. Refunds may take up to 21 days to be issued after your return is received. When you complete your purchase, we are no longer able to change or cancel your order. The information you submit with your PayPal payment will be automatically processed. We cannot update your address, split shipments, combine shipments, or cancel your order. Please contact us with any special requests before ordering. Contact Information phone: 1-888-311-4455 (toll free) phone: 1-440-602-7080 (local and international) We are available m-f 11am-5pm EST Scroll down and click on "ask a question" if you would like to send us a message Item description is automatically generated with information from manufacturer product catalogs and other content providers. Please excuse any image and typographical errors.
