New Setra 225g100pgc42cb1 Uhp Pressure Transducer 0-100 Psig, Out 0-10 V Gct-225

US $5200

Phoenix, Arizona, United States
Nov 18th

Open on mobile:
QR code

NEW Setra 225G100PGC42CB1 Ultra-High Purity Pressure Transducer Comes with what you see in the pictures. If you don't see it, you probably won't get it. Specifications are from Setra and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This part is new, old stock from surplus Novellus/ASM inventory The Unit's Serial Number Tag Reads: Model Number: 225 Part Number: 225G100PGC42CB1 Serial Number: Many available Range: 0-100 PSIG Exciter: 13-30 VDC Output: 0-10 VDC Breakdown by Part Number: Model: 225 Pressure Range: 0 to 100 PSI Pressure Type: Gauge Fitting: #4 Male Face Seal Swivel Output: 0 to 10 VDC Output: 4-Pin Bayonet Connector Link to the Datasheet: Setra 225 Series Pressure Transducer Datasheet Link to the Manual: Setra 225 Series Pressure Transducer Manual Benefits: Superior Stability Avoids Downtime EMI/RFI Immunity Prevents False Shutdown Sturdy Design Allows Trouble-Free Installations CE & RoHS Compliant Applications: High Purity Gas Delivery Systems Semiconductor Process Tools Gas Cabinets Description: Setra's Model GCT-225 series is suited for ultra-high purity gas delivery systems semiconductor processes, and control applications that require ultra-clean operating, high throughput performance, and exceptional long-term stability. The Model GCT-225 series comes with a rotatable cover for easy access to 12-turn potentiometers for fine zero and span adjustment. Specifications: Performance Data: Accuracy RSS1 (at constant temp): ±0.25% Non-Linearity, (BSFL): ±0.15% FS Hysteresis: 0.20% FS Thermal Effects2: Compensated Range: +15°F to +150°F (-9°C to +65°C) Zero Shift: 2.0 %FS/100°F (1.8 %FS/50°C) Span Shift: 2.0 %FS/100°F (1.8 %FS/50°C) Leak Tested: Mass Spectrometer Helium Leak Tested 1 x 109 ATM CC/Sec. Pressure Media : Liquids or gases compatible with 216L Stainless Steel Physical Description: Case: Stainless Steel Electrical Connection: 4-Pin Bayonet Connector Pressure Fitting: #4 Male Face Seal Swivel Vent: Through Cover Internal Cavity Volume: 0.11 in.3 Wetted Material: VAR 316L SS Electropolished to 7 RA (10 max.) Finish Weight (Approx.): 4 ounces (113 grams) Environmental Data: Operating Temperature3: -40°F to +185°F (-40°C to +85°C) Storage Temperature: -40°F to +185°F (-40°C to +85°C) Electrical Data (Voltage): Circuit: 3-Wire (Exc, Out, Com) Excitation: 10 to 30 VDC for 5 V FSO, 13 to 30 VDC for 10 V FSO Output: 0 to 5 VDC or 0.2 to 5.2 VDC5, 0 to 10 VDC or 0.2 to 10.2 VDC5 Power Consumption: 0.08 watts Output Impedance: 100 ohms Warm-Up Shift: ±0.1% FS Total Notes: 1: RSS of Non-Linearity, Non-Repeatability and Hysteresis. 2: Units calibrated at nominal 70°F. Maximum thermal error computed from this datum. 3: Operating temperature limits of the electronics only. Pressure media temperatures may be considerably higher or lower. 4: Calibrated into a 50K ohm load, operable into a 5000 ohm load or greater. 5: Zero output factory set to within ±25 mV (for 5 VDC output), or ±50 mV (for 10 VDC output). 5: Span (Full Scale) output factory set to within ±25 mV (for 5 VDC output), or ±50 mV (for 10 VDC output). For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $10.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I need to know the following information: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 11/17/16
