New South Smaller Galaxy G6 Gnss Rtk Gps Rtk Receiver

US $4,500.00

chengdushi, China
Jul 19th

Open on mobile:
QR code

Specification GNSS performance Channels 336, 220 (optional) GPS L1C/A, L1C, L2C, L2E, L5 GLONASS L1C/A, L1P, L2C/A, L2P, L3 BDS B1, B2, B3 GALILEO E1, E5A, E5B, E5AltBOC, E6 SBAS L1 C/A, L5 QZSS, WAAS, MSAS, EGNOS, GAGAN L-Band Trimble RTX Positioning output rate 1Hz~50Hz Initialization time <10s Initialization reliability >99.99% Positioning precision Static surveying Horizontal: 2.5mm+0.5ppm RMS; Vertical: 5mm+0.5ppm RMS Code differential positioning Horizontal: 0.25m+1ppm RMS; Vertical: 0.50m+1ppm RMS Real-time kinematic surveying Horizontal: 8mm+1ppm RMS; Vertical: 15mm+1ppm RMS RTX Horizontal: 4-10cm; Vertical: 8-20cm SBAS positioning Typically<5m 3DRMS xFill Horizontal: 5+10mm/min RMS; Vertical: 5+20mm/min RMS IMU tilt compensation -- Single positioning -- User interaction Operaing system Linux Buttons Double buttons and visual operation interface LCD 0.96 inch HD OLED screen, the resolution is 128 x 64 Indicators -- Web UI Accessing by WIFI or USB mode to monitor the receiver Voice guide iVoice intelligent voice technology provides status and operation voice promptly, Supports Chinese, English, Korean, Russian, Portuguese, Spanish, Turkish Secondary development Providing secondary development package, and opening the OpenSIC observation data format and interface definition for secondary development Data cloud service Web page cloud service management platform, supporting online register etc Hardware performance Dimension 152mm (diameter) 137mm (height) Weight 1.44kg (including battery) Material Magnesium alloy shell Operating temperature -45°C ~ +60°C Storag temperature -55°C ~ +85°C Humidity 100% Non-condensing Waterproof/Dustproof IP67 standard, protected from long time immersion to depth of 1m, and fully protected against blowing dust Shock and vibration MIL-STD-810G standard vibration test certified Power Supply 9-25V wide voltage DC design, with overvoltage protection Battery High capacity removable battery with the indicator displaying the power usage, 7.4V, 6800mAh/per Battery solution (Providing the 7 24h battery solution) Battery life More than 30h (static mode), More than 15h (RTK mode) Communications I/O port 5-PIN LEMO port, 7-PIN USB port (OTG), 1 network/radio data link antenna port, SIM card slot Wireless modem Integrated internal radio receiver and transmitter 1W/2W/3W Frequency Range 403-473MHz Communication Protocol Trimtalk450S, SOUTH, SOUTH+, SOUTHx, huace, ZHD, Satel Cellular Mobile Network TDD-LTE, FDD-LTE 4G network modem Double Module Bluetooth BLEBluetooth 4.0 standard, Bluetooth 2.1 + EDR standard NFC Communication Realizing close range (shorter than 10cm) automatic pair between receiver and controller External Devices -- WIFI Standard IEEE 802.11 b/g WIFI Hotspot Adopting the WIFI hot spot function, any smart terminals (controller, cellphone and PC) can connect to the receiver easily WIFI data link The receiver can transmit and receive correction via WiFi Data storage/ Transmission Data Storage 8GB internal storage, supports external USB data storage, changeable record interval, supports up to 50Hz raw data collection Data Transmission USB data transmission, FTP download, HTTP download Data Format Static data format: STH, Rinex2.x and Rinex3.x etc Differential data format: CMR+, CMRx, RTCM 2.1, RTCM 2.3, RTCM 3.0, RTCM 3.1, RTCM 3.2 GPS output data format: NMEA 0183, PJK plane coordinates, binary code, Trimble GSOF Network model support: VRS, FKP, MAC, supporting NTRIP protocol Inertial sensing system Tilt survey Built-in tilt compensator, correcting coordinates automatically according to the tilt direction and angle of the centering rod Electronic bubble Controller software display electronic bubble, checking leveling status of the centering rod real time Thermometer Built-in thermometer sensors, adopting intelligent temperature control tech nology, monitoring and adjusting the receiver temperature in real time

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Type	GPS Receiver
Brand	SOUTH
MPN	0767155165199
UPC	767155165199
