New Tektronix Tla7aa4 136-channel Logic Analyzer Module Vxi W/opt. Tla7aa48s 8mb

US $2,499.99

Phoenix, Arizona, United States
Feb 15th

Open on mobile:
QR code

Click Here. Double your traffic. Get Vendio Gallery - Now FREE! NEW Tektronix TLA7AA4 Logic Analyzer Module with Option TLA7AA48S Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from Tektronix and may vary slightly due to upgrades, options, or revisions this unit may or may not have. 2 modules available, only 1 sold in the auction. They are both brand-new, old stock. They are guaranteed to work for 30-days, parts and labor, excluding freight. List Price was: Standard Module - TLA7AA4: $20,100.00 NEW from Tektronix Option 8S - TLA7AA48S: $38,900.00 NEW from Tektronix Total List Price is: $59,000.00 Description by Model Number: TLA7AA4 - TLA700 Logic Analyzer Module, 136 Channels, 8 GHz Magnivu Timing, 120 MHz State (Opt. 8S changes this to 235 MHz), 128 KB Memory Depth (Opt. 8S changes this to 8 MB) with 136 CH-TO-4-CH, 2 GHz Bandwidth, IVIEW Analog Probe Outputs TLA7AA48S - Increase to 8 MB Memory Depth @ 235 MHz State Speed The Unit's Serial Number Tag Reads: Model Number: TLA7AA4 Serial Number: B012334 Module Firmware Version: 4.4 Logic Analyzer Module - 136 Channel 8S - 8Mb Memory Depth @ 235 MHz State Speed Link to the Datasheet: Tektronix TLA7Axx Series Logic Analyzer Module Datasheet Features & Benefits: 136 Channel Logic Analyzers with 8 Mb Depth 500 ps (2 GHz)/32 Mb Deep Memory Timing Analysis MagniVu Acquisition Technology Provides up to 125 ps (8 GHz) Timing Resolution to Find Difficult Problems Quickly Up to 800 MHz State Acquisition Analysis of Synchronous Digital Circuits Simultaneous State, High-speed Timing, and Analog Analysis Through the Same Probe Pinpoints Elusive Faults Without Double Probing Glitch and Setup/Hold Triggering and Display Finds and Displays Elusive Hardware Problems Transitional Storage Extends the Signal Analysis Capture Time Simultaneous Analog and Digital Measurements Through the Same Probe Compression Probing System With 0.5 pF Capacitive Loading Eliminates Need For On-board Connectors, Minimizes Intrusion on Circuits and is Ideal for Differential Signal Applications Broad Processor and Bus Support Applications: Hardware Debug and Verification Processor/Bus Debug and Verification Including Source Synchronous Clocking Embedded Software Integration, Debug and Verification Breakthrough Solutions for Real-time Digital Systems Analysis: Today's digital design engineers face daily pressures to speed new products to the marketplace. The TLA7Axx Series logic analyzer modules answer the need with breakthrough solutions for the entire design team, providing the ability to quickly monitor, capture and analyze real-time digital system operation in order to debug, verify, optimize and validate digital systems. Hardware developers, hardware/software integrators and embedded software developers will appreciate the range of capabilities of the TLA7Axx Series logic analyzer modules. Its broad feature set includes capturing and correlating elusive hardware and software faults; providing simultaneous state, high-speed timing, and analog analysis through the same probe; using deep state acquisition to find the cause of complex problems; real-time, non-intrusive software execution tracing that correlates to source code and to hardware events; and non-intrusive connector less probing. The TLA7Axx Series logic analyzer modules offer Tektronix' breakthrough MagniVu technology for providing high-speed sampling (up to 8 GHz) that dramatically changes the way logic analyzers work and enables them to provide startling new measurement capabilities. The TLA7Axx modules offer high-speed state synchronous capture, high-speed timing capture and analog capture through the same set of probes. They capitalize on MagniVu technology to offer up to 125 ps timing on all channels, glitch and setup/hold triggering and display and timestamp that is always on at up to 125 ps resolution. The TLA7Axx also offers new capabilities to capture source synchronous applications. For More Pictures Please Click the Following: Picture 2 - Front View Picture 3 - Back View Picture 4 - Right View Picture 5 - Left View Picture 6 - Serial Number Tag For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $25.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I need to know the following information: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 10/17/08 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Tektronix
Model	TLA7AA4 w/TLA7AA48S
