New Tes-3600 3 Phase Power Analyzer Tester True Rms With Software,free Shipping

US $1,349.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

NEW TES-3600 3 Phase Power Analyzer Tester True RMS with Software,Free shipping 10 Display Easy - to - View LCD Screen. Connectors for 4 Current Sensing Clamps. 1P2W, 1P3W, 3P3W2M & 3P4W Power Measurement. True RMS Sensing. Power KW, KVAR, KVA, PF, ? ,Hz, & Energy KWh, KVARh & KVAh Measurement. Phase sequency indicator function. Backlight display function. Manual Data Memory and Read (99 sets). Data Logging (512KB Memory, 20,000 sets) Programmable Trigger - Points and Start / Stop Time. RS-232 Optical Interface with three phase voltage / current Waveform display and Harmonic analysis. Easy - to - use Push - Button Operation. Light Weight, Portable Design. Voltage Measurement (V) Ranges Method Accuracy Input impedance 600.0V True RMS ± 0.5%rdg ± 10dgts (>30V) 2M ? Current Measurement (A) Ranges Method Accuracy 250A, 500A, 1000A True RMS ± 0.5%rdg ± 10dgts + clamp on sensor specifications Active Power Measurement (KW) Ranges Accuracy Effect of power factor 600.0KW ± 0.5%rdg ± 10dgts + clamp on sensor specifications ± 0.1%rdg Reactive Power Measurement (KVAR) Ranges Accuracy Effect of power factor 600.0KVAR ± 0.5%rdg ± 10dgts + clamp on sensor specifications ± 0.1%rdg Apparent Power Measurement (KVA) Ranges Accuracy 600.0KVA ± 0.5%rdg ± 10dgts + clamp on sensor specifications Power Integration Measurement Power Integration Resolution Accuracy 0.0KWh to 9999MWh 0.1KWh ± 0.5%rdg ± 10dgts + clamp on sensor specifications 0.0Kvarh to 9999Mvarh 0.1Kvarh 0.0KVAh to 9999MVAh 0.1KVAh Power Factor Measurement Ranges Accuracy Polarity display -1.000(lead) to 0.000 to + 1.000 (lag) ± 1dgt for each calculation from measured values When the current lags the voltage unsigned ; when the current leads the voltage : "-". Frequency Measurement Ranges Measurement source Accuracy 40Hz to 100Hz Voltage U1 ± 0.5%rdg ± 1dgt General Specifications Size 235(L)x116(W)x54(H)mm (9.3"Lx4.6"Wx2.1"H) Operating Temperature and Humidity 0 ?C to 50 ?C (32 ?F to 122 ?F ) R.H. < 80% non-condensing Storage Temperature and Humidity - 10 ?C to 60 ?C (14 ?F to 140 ?F ) R.H. < 70% non-condensing Accessories 1) Instruction manual 2) Software CD Rom / Optical RS-232 interface 3) Deluxe carrying case 4) Battery ("AA" 1.5V x 8pcs ) 5) AC adaptor (110V -> 12V ; 220V -> 12V) 6) 4pcs current clamp transducer (1, 2, 3, 4 cable length 3 meters) (1000A AC, jaw opening 40mm) 7) 4pcs crocodiles test leads (blue, yellow, red, black, wire length 3 meters) Edited by Johnny PAYMENT INFORMATION: 1.We can accept Credit Cards,Paypal,T/T,Escrow and so on. 2.The buyer is responsible for any tax and/or duty charged by their country. INTERNATIONAL SHIPPING: The package will be shipped by DHL, FEDEX or EMS. After we shipped the parcel,we'll fill in the tracking number and inform you by e-mail.Please write the correct address and telephone number when you make orders,so the courier can contact you when they deliver the parcel to you. thanks WARRANTY INFORMATION: 1.All the products have been checked and packed in good condition before dispatch. 2.All the products with one year warranty. 3.If you find any quality problems,please send it back within 3 days,and we'll send you a new one or refund you the payment after we get the returned one. 4.Buyers have to pay for the return cost and we will pay the cost for resend 5.All products returned should be in new conditions. CONTACT US: Office Tel: 008675527541660 Cellphone: 008615967476828 1.A good feedback is very important for our store,if you feel satisfied with our products,please give us positive feedbacks. 2.Please contact us before leaving any negative or neutral feedback,We will work with you to solve any problems.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	TES
Model	TES-3600
