New Unico 1100 Vfd Variable Frequency Flux Vector Control Ac Drive Servo Motor

US $875.00

Twin Lakes, Wisconsin, United States
Jan 29th

Open on mobile:
QR code

This was acquired through a federal bankruptcy sale. It was found in the original manufacturer supplied shipping crate. It looks to be new. We assume it is. It does have two knock outs(see photos) on one side. 1100 Variable-Frequency AC Drive For applications requiring variable-frequency or flux vector control of medium to large induction or synchronous AC motors. Operates from 200-240, 380-480, or 500-600 V AC three-phase supplies for power requirements up to 600 hp (450 kW). Brochure Sophisticated control in an easy-to-use package Specifications Electrical Input Supply Voltage 200 to 240, 380 to 480, or 500 to 600 V AC, three-phase Voltage Tolerance –40% of minimum, +10% of maximum Frequency 47 to 63 Hz Displacement Power Factor 0.95 at rated load for 6-pulse 0.97 at rated load for 12-pulse 0.99 at rated load for 18-pulse Output Rating Voltage Zero to input supply voltage, three-phase Frequency Zero to 120 Hz for transducerless vector control Zero to 180 Hz for transducer-based vector control Zero to 300 Hz for variable-frequency control Switching Frequency 16 MHz control: 1, 2, 4, 8, and 16 kHz 20, 40, and 100 MHz controls: 1 to 12 kHz, programmable Service Conditions Efficiency 97% nominal at rated switching frequency Overload Current Torque Overload (1 min) Maximum Constant 150% to 200% of rated 200% of rated Variable 120% to 150% of rated 140% to 160% of rated Extended 110% to 120% of rated 120% to 140% of rated Environmental Operating Temperature Control section: 32° to 131° F (0° to 55° C) Heat sink (standard): 32° to 104° F (0° to 40° C) Heat sink (derated): 32° to 122° F (0° to 50° C) Storage Temperature –40° to 158° F (–40° to 70° C) Operating Humidity 95% maximum, noncondensing Altitude To 3,300 ft (1,000 m) without derating Performance Frequency Control Range Zero to base speed at full torque Base speed to 300 Hz at constant power Resolution 0.024% with analog input (12-bit) 0.1 Hz with digital input Velocity Control Range Zero to base speed at full torque Base speed to 180 Hz at constant power with transducer Base speed to 120 Hz at constant power without transducer Regulation ±0.001% of base speed, down to zero, with transducer ±0.5% of base speed, 2 Hz and above, without transducer Torque Control Starting Torque Constant torque: zero to 150% of rated Variable torque: zero to 120% of rated Extended torque: zero to 110% of rated Regulation ±3.0% of maximum with transducer ±10% of maximum without transducer Inputs and Outputs Analog Inputs Three (3) 12-bit analog inputs (±10 V DC or 0 to 20 mA) Analog Outputs Two (2) 12-bit analog outputs (±10 V DC and 0 to 20 mA) Digital Inputs Twelve (12) digital inputs (require sink of 1 mA to common) Converter Interface Module: Provision for input converters rated 2.5 to 28 V DC @ 30 mA, 90 to 140 V AC @ 11 mA, and 180 to 280 V AC @ 5 mA Digital Outputs Six (6) digital outputs (open-collector drivers rated 24 V DC @ 500 mA) Converter Interface Module: Provision for output converters rated 5 to 60 V DC @ 3 A, 12 to 140 V AC @ 3 A, or 24 to 280 V AC @ 3 A; or for normally open or normally closed relay converters rated 250 V AC @ 8 A Serial Communications Asynchronous Port(s) One RS-232/422/485, isolated, and two auxiliary RS-422/485 Protocols ANSI-x3.28-2.5-A4 or Modicon RTU, standard Synchronous Port RS-485 for high-speed master/slave networking Communication Modules Anybus One module provision Options: CANopen, CC-Link, ControlNet, DeviceNet, Ethernet, Interbus, LonWorks, Modbus Plus, Profibus DPV1, Profibus Master Bluetooth or MaxStream 100 MHz control: one module provision 280 MHz control: two module provisions MaxStream options: 900 MHz and 2.4 GHz Protection The following hardware conditions are detected. Additional protective features are provided by the application software. • Ground fault • Phase-to-phase short circuit • DC bus overvoltage • DC bus undervoltage • Instantaneous overcurrent • Motor overload • Heat sink overtemperature • Ambient overtemperature • Power transistor fault • Logic power undervoltage • Memory malfunction • Processor not running fault Options Transducers A motor-mounted incremental encoder or resolver and corresponding interface may be used for highest performance. The resolver interface provides an encoder emulation for paralleling feedback to other devices. Dual- and triple-encoder options are also available for position-following or dual-transducer applications. Expanded Analog I/O An analog interface module may be used instead of a feedback interface to expand the analog I/O capabilities of the drive. The module provides eight additional inputs and four additional outputs. Dynamic Braking The dynamic braking option is factory installed in the drive. Appropriately sized external braking resistors are required. Packaged Drives Drives may be ordered as part of a packaged system including a circuit breaker, operator devices, and additional system components mounted inside a NEMA 4 (IP66) enclosure. Power Range Input Voltage Constant-Torque Applications Variable-Torque Applications Extended-Torque Applications 230 V AC 11/2 -60 hp (1.1-45 kW) 2-75 hp (1.5-55 kW) – 380 V AC 11/2-350 hp (1.1-262 kW) 2-400 hp (1.5-300 kW) – 460 V AC 11/2-350 hp (1.1-262 kW) 2-400 hp (1.5-300 kW) 25-500 hp (18-375 kW) 575 V AC 11/2-400 hp (1.1-300 kW) 2-500 hp (1.5-375 kW) 25-600 hp (18-450 kW) 1100 Variable-Frequency AC Drive For applications requiring variable-frequency or flux vector control of medium to large induction or synchronous AC motors. Operates from 200-240, 380-480, or 500-600 V AC three-phase supplies for power requirements up to 600 hp (450 kW). Brochure

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“NEW UNUSED.”
