Newest Dc 12-36v 500w Brushless Motor Controller Hall Balanced Car Driver Board

US $390

Shen Zhen, China
May 24th

Open on mobile:
QR code

NEWEST DC 12-36V 500W Brushless Motor Controller Hall Balanced Car Driver Board Description This is a high capacity driver module for brushless DC motor, another cost-effective choice for your motion control needs. Module Specs: Working Voltage: 12 - 36V DC Drive Current: max 15 amp Drive Capacity: max 500 Watts (this relates to working voltage) Speed control: Yes Direction Control: Yes Over-current protection: Yes (15 amp) Short circuit protection: Yes Module Size: 63 * 43 * 17mm Left (Up): 5V: Output 5V Z/F: DIR (cw / ccw) VR: Speed control GND: GND Right: VCC: Input (12~36V) GND: power - MA, MB, MC: Motor Wire A, B, C About Heat Sink: The package includes the module only. Heat sink is NOT included. (heat sink has relatively heavy weight and costs more than its own value in international shipping). If buyer still needs heats sink and are aware of the higher cost, please contact us in advance prior to order. Before using the module, user must match a proper heat sink for the module. Otherwise the module will be damaged for over heat. Without heat sink, the allowed power range for the module will be much lower limited. Recommended Size of heat sink: over 200 cm2 (square cm). The module's output consists of 6 pieces of 80Amp CMOS, with high power capacity. When adding heat sink, please pay attention to insulation for the 6 CMOSes. About Connections: 5V: the module outputs 5V for external potentiometer to adjust speed (when not using potentiometer, please DO NOT connect it to other external circuit, otherwise will damage the module) Z/F (CW / CCW): control motor direction (CW when not connected, CCW when connected to 5V) VR - Speed control: input 0.5 to 5V DC, motor speed adjustable from 6% to 100% (for a normal potentiometer, center pin of pot connect to this point, and two side wires of pot to 5V and GND) GND: ground for speed control voltage VCC: power in positive: voltage 12V to 36V DC GND: power in negative A/B/C motor wires: can be connected randomly to three groups of coils of motor. If the phase is wrong, then the motor running wrong direction. We can then change randomly two wires connection to change motor direction. Package Contents 100% Brand New 1x High Capacity 12-36V Brushless DC Motor Driver Speed Controller Module Payment We only accept PayPal.PayPal is the only online payment method we accept. Please make sure you have a valid/confirmed PayPal account prior bidding. Payment must be received within 7 days of the close of auction. Unpaid auction wins will be forfeited after 7 days and a Non-Paying Bidder alert will be filed with eBay to recover the closing fees of the auction. shipping We only accept your Ebay Address,Please Make sure it's 100% right. The items you ordered will be shipped out in 2 business day by Air Mail when your payment is clear. Delivery time Country Working Day 5-8 9-13 14-18 19-24 >30 United State Rate (item arrived) 20% 55.36% 21.72% 1.92% Refund Other Country 5% 37.1% 46.4% 10.5% Refund Warranty and Guarantee 60 days warranty will apply to all our products. If you have questions on the following issues please contact us immediately ! You don’t satisfy the item. Item don’t fit your car perfect. Item arrived is defective, broken or incomplete. You don’t receive the item within 24 days. You receive the wrong item. If the product is assessed to the problem above.Buyers will receive a full or partial refund, or a replacement product or parts. When buyers are asked to send back the defective item, a replacement will be sent to buyers after the returned product is received. We will take full responsibility for the postage fee.Replacement products are provided with the same warranty as the returned products. Customer Satisfactory Note: Do not hesitate to contact us anytime before and after your purchase, we are committed to your 100% customer satisfaction. We back our commitment with superb service, 100% full money back and a customer satisfaction guarantee. I am here and ready to assist you with any questions or concerns you might have before or after the purchase. My goal is to make sure you are a happy customer and pleasant shopping with us. When you shop with us, your satisfaction is our #1 priority. Bid With Confidence! Return 1.In case of defectiveness, return must be requested within 14 business days after received the item. 2.Return item must be in brand new condition which means it is never installed and kept in the original packaging. 3.Replacement or refund will be made as the item received and refund will only available to your PayPal account. 4.No replacement or refund will be made for any damaged caused by accidentally using. 5.By buying this item you automatically agree with our rules, terms and conditions.
