Newport 433 Series Precision Linear Translation Stage W Motorized Oriel1" Driver

US $149.00

  • Wadsworth, Illinois, United States
  • May 3rd
Open on mobile:
QR code
High-Performance Low-Profile Ball Bearing Linear Stage, 1.81 in.,1/4-20 The model 433 translation stage with its large 3 in. x 4 in. platform features exceptional performance, usability, and value with precision ball bearing construction – hardened balls rolling between opposing pairs of hardened and polished stainless steel rods providing better than 200 microradian angular deviation. For stability, repeatability, and exceptionally smooth motion, actuators bear upon a hardened carbide insert. Springs provide preload against the actuator tip to eliminate backlash. Although the stage is capable of traveling a full 1.8 in. (46-mm) with the SM-50 micrometer drive, the actuator mounting blocks can be relocated to accommodate 1.0 in. (25.4) drives like the SM-25. This stage can also be reconfigured into a left-handed version with the micrometer on the opposite side. A non-influencing lock (also reversible for left-handed configuration) provides positive stable positioning and guards against inadvertent adjustments. Actuators for this stage are usually sold separately.  This set included 1' motorized actuator with cable and male 1.5 mm connector that allow it connection to Newport or other type motor drivers. It will work with +/- 1-12 V suply and it is completely reversible. The actuator allows  for extremely high resolution motion.
“Used very good, mechanically perfect conditions”
Brand Newport Aerotech Oriel
Country/Region of Manufacture United States
Model 433
