Newport 462 Xyz-m Side Drive Stage Ultralign Precision Adjustable, New In Box

US $825.00

  • San Diego, California, United States
  • Jan 30th
Open on mobile:
QR code
Brand new item still sealed in original box from newport. Feel free to ask and questions. The M-462-XYZ-SD ULTRAlign™ Precision Integrated Crossed-Roller Bearing Linear Stages feature stainless steel construction for high stability, with thermally matched, hardened steel crossed-roller bearings for unsurpassed performance and a side drive for a small footprint. The crossed-roller bearings and precision-manufactured bearing reference surfaces provide exceptionally linear 25.4 mm XYZ travel, with angular deviation better than 100 µrad about any axis. Our analysis has shown that optimum stability demands that not only the stage be built of stainless steel, but also the angle brackets, actuator mounts, and even the assembly hardware. ULTRAlign stages overcome the limitations of multi-axis stages derived from traditional tooling industry designs. The actuators are located out-of-the-way of oversized loads. Generous M6 hole patterns provide easy mounting. The mounting base can be removed for a lower profile. Each axis features a non-influencing locking mechanism for negligible motion of the stage when locking or unlocking. Specially designed actuator mounting blocks allow quick and easy actuator changes, on any axis, at any time. Actuators are not included. Model                                  M-462-XYZ-SD Travel Requirements           1.0 in. (25.4 mm) Axes of Travel                     X, Y, Z Travel                                  1.00 in. (25.4 mm) Bearings                               Crossed-Roller Bearings Material                               Stainless Steel Thread Type                         M6 Load Capacity, Vertical       15 lb (67 N) Precision                              Very High Base Material                       Stainless Steel Angular Deviation                <100 µrad Special Features                   Guaranteed Travel Straightness Actuators Required              Sold Separately Type                                     Precision
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Newport
Model M-462-XYZ-SD
