Newport 561D ULTRAlign Precision Alignment Stage,6 mm XZ,13 mm Y, w/1 Micrometer, US $400 – Picture 0
Newport 561D ULTRAlign Precision Alignment Stage,6 mm XZ,13 mm Y, w/1 Micrometer, US $400 – Picture 0

Newport 561d Ultralign Precision Alignment Stage,6 Mm Xz,13 Mm Y, W/1 Micrometer

US $400

  • San Luis Obispo, California, United States
  • Jun 6th
Open on mobile:
QR code
Newport 561D-YZ ULTRAlign Precision Fiber Alignment Stage, 6 mm Z, 13 mm Y w/1 Micrometer One Micrometer Included. For actual micrometers, please see gallery pictures.  Model: 561D-XYZ » View Series Overview ULTRAlign Precision Fiber Alignment Stage, 6 mm XZ, 13 mm Y The 561D-XYZ ULTRAlign™ Linear 3 Axis Stage features stainless steel construction for superior long-term stability, with thermally matched, hardened steel crossed roller bearings for unsurpassed performance. The crossed roller bearings and precision-manufactured bearing reference surfaces provide exceptionally straight 6mm linear travel in X and Z, with angular deviation better than 100 µrad about any axis. The Y axis provides 13 mm of travel. We measure each stage on a six-axis interferometer to ensure performance. 561 Series Stages have been specifically designed for precision fiber alignment. A top-mounted rail permits precise and secure attachment of an array of fiber and device holders. A tilt platform can be attached for two-axis tip/tilt alignment of fibers to devices. And a goniometer is available to provide rotation about the fiber axis. With up to six degrees of freedom, high-performance ULTRAlign stages offer a superior fiber optic alignment solution. Three actuators are required and are not included. Model 561D-XYZ Type ULTRAlign™ Fiber Alignment Stages Bearings Crossed Roller Travel 0.5 in. ( 13 mm) Load Capacity 5 lb ( 22 N) Material Steel Thread English Optical Axis Height 3.125 in. ( 79.4 mm) Actuators Required 3 (1 Included) Angular Deviation <100 µrad
