Newport 561d-xyz Ultralign Laser Precision Fiber Alignment 3 Axis Linear Stage

US $979.00

Hornell, New York, United States
Jan 30th

Open on mobile:
QR code

NEWPORT 561D-XYZ ULTRAlign LASER PRECISION FIBER ALIGNMENT 3 AXIS LINEAR STAGE You are bidding on a NEWPORT 561D-XYZ ULTRAlign LASER PRECISION FIBER ALIGNMENT 3 AXIS LINEAR STAGE. The 561D-XYZ ULTRAlign™ Linear 3 Axis Stage features stainless steel construction for superior long-term stability, with thermally matched, hardened steel crossed roller bearings for unsurpassed performance. The crossed roller bearings and precision-manufactured bearing reference surfaces provide exceptionally straight 6mm linear travel in X and Z, with angular deviation better than 100 µrad about any axis. The Y axis provides 13 mm of travel. Each stage was measured on a six-axis interferometer to ensure performance. 561 Series Stages have been specifically designed for precision fiber alignment. A top-mounted rail permits precise and secure attachment of an array of fiber and device holders. A tilt platform can be attached for two-axis tip/tilt alignment of fibers to devices. And a goniometer is available to provide rotation about the fiber axis. With up to six degrees of freedom, high-performance ULTRAlign stages offer a superior fiber optic alignment solution. Three actuators are required and are not included. Model 561D-XYZ Type ULTRAlign™ Fiber Alignment Stages Load Capacity 22 N ( 5 lb) Bearings Crossed Roller Angular Deviation <100 µrad Optical Axis Height 3.125 in. ( 79.4 mm) Travel 3 mm Base Material Stainless Steel Actuators Required 3 The 561D-XYZ ULTRAlign comes with the Newport 561 OBJ Microscope Objective Lens Mount and the Newport M-40X 0.65 Microscope Objective Lens Optical. Microscope Objective Lens, 40x, 0.65 NA, 4.5 mm Focal Length The M-40X microscope objective has a 40x magnification, 0.65 numerical aperture, 4.5 mm focal length, and 5.0 mm clear aperture. The objective is corrected for a rear conjugate at 160 mm. The lenses are antireflection coated with MgF2 for the visible spectrum. This M-40x objective is suitable for use with either the Model 900 or 910A spatial filters. M- series microscope objective power is based on a 160 mm tube length. MP = 160 mm/f Model M-40X Type Objective Lenses Magnification 40x Effective Focal Length 4.5 mm Wavelength Range 400-700 nm Working Distance 0.6 mm Input Beam Diameter 4.0 mm Calculated Pinhole Diameter 5.7 µm Recommended Pinhole Diameter 10 µm Objective Lens Mount The 561-OBJ Objective Lens Mount can mount microscope and laser diode objective lenses to a 561 Series stage. The mount uses a standard 0.800-36 RMS thread. Model 561-OBJ Type ULTRAlign™ Fiber Alignment Accessories Precision Very High These are the retail prices for these components sold through Newport: 561D-XYZ ULTRAlign LASER FIBER ALIGNMENT STAGE - Retail $1650.00 561 OBJ Objective Lens Mount - Retail $110.00 M-40X Microscope Objective Lens - Retail $192.00 These components were not specifically manufactured for an individual application; therefore be sure to check the dimensional descriptions carefully for your application. Future returns or requests for refunds, because of some "fit" issue or the like will not be honored. Please check the other component variants that are available in my listings for the model or models that best fits your requirement. Your imagination is the only limiting factor in the spectrum of possible applications for these components and materials. If you require additional technical information, design, or application engineering consultation, feel free to contact us. As a materials scientist with four decades experience in high temperature processing, ceramics, dentistry, and jewelry manufacture it will be possible to provide you with creative and imaginative approaches to your requirements. Feel free to ask any questions you may have regarding this item early. Use PayPal only. Combined shipping discount is provided for multiple item purchases. For best results, please be sure to shop using cart, then complete the paying transaction when you are satisfied that all the items you need are in the cart. Items purchased separately will be shipped separately as a unique transaction. Please complete payment transactions within 3 days. Items are generally shipped via USPS first class mail with delivery confirmation. Ask about shipping costs to your country. Feedback is provided for all buyers. We will appreciate yours as well. We strive to maintain excellent customer service; and are able to solve virtually any issues you may have. Every effort to provide the most accurate information about this item and every appropriate precaution in packaging this item is made, to assure that your highest expectations and satisfaction are met, and are exercised to meet this requirement for excellence. In winning this auction or purchasing this item you are agreeing that you will first provide the seller every opportunity to provide redress or resolution to any issues you many have concerning this item, prior to leaving any negative feedback about the seller or the item.

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“In excellent unused condition without original packaging”
