Newport/klinger/microcontrole Precision Linear Stage 25mm Travel 10um Resolution

US $400

Laguna Niguel, California, United States
May 25th

Open on mobile:
QR code

One (1) Klinger / Micro Controle 80 x 80 x 18 mm linear stage with micrometer drive Features: Stainless Steel construction. Travel: 25 mm / 0.984" in marked 10 um increments. Stage plate is 80 x 80 mm, overall, including endplates (less micrometer) 80 x 93.45 mm. The micrometer adds about 69 mm to the length when fully extended. Stage height is 18 mm. The aperture is 38 mm x 49 mm. There are four (4) threaded mounting holes on top ( for 4 mm / M4 screws ) arranged as a 63 mm square. There are also four (4) through holes on top for connecting to a second identical stage ( for an XY pair ) they are arranged as a 34 mm square and are counter-bored on the bottom side of the top plate. If you purchase more than 1 of these stages I'll include screws to facilitate XY connection. The bottom plate has four M4 threaded holes with spacing that matches the above mentioned through holes. The moving part of the stage is spring loaded against the micrometer to reduce or eliminate backlash. Fully functional and ready to use. Micro Controle and Klinger merged some time ago. Both are now a part of Newport Corp. Similar items are available in the Opto-Mechanical section of my eBay store: http://stores.ebay.com/genera/Opto-Mechanical-/_i.html?_fsub=8150460011 __________________________________________________________________________________________________________ PayPal only for domestic sales except local pick-up. Local pick-up my be possible but I'll require cash at time of delivery. ( Because delivery can't be verified to eBay or PayPal standards for proof of delivery should a delivery dispute arise ). Delivery fees will be waived for local pick-up. Orders over $200 will require an adult signature. I'll be happy to combine shipping but keep in mind that it isn't always practical. Contact me with your set of items, before bidding, if this is important to you. California sales tax ( 8.00% ) will be added for CA deliveries unless your valid resale certificate is provided prior to checkout ( this includes local pick-ups ). International shipping is available: Payment through PayPal is preferred but wire transfers (for amounts over US$500) are also accepted. Please contact me prior to bidding for shipping costs. I can often find a rate lower than that calculated by eBay. Imports fees, duties, or taxes are your responsibility as the buyer. They are not included in the item's sale price or shipping cost.
