Newport Uzm80cc.1 Motorized Vertical Translation Stage, Esp-compatible

US $580

Asheville, North Carolina, United States
Jun 4th

Open on mobile:
QR code

Newport UZM80CC.1 motorized vertical translation stage. Tested, fully functional, and in excellent physical condition. Bottom mounting plate included. This stage is equipped with a UE31CC dc servo motor and is ESP-compatible. The stage provides 4mm travel range with 0.1um resolution and 0.25mm/sec maximum speed. The UZM Series vertical translation stages offer high-precision vertical translation for applications requiring submicron resolution accuracy. High-resolution vertical motion is achieved with a precision inclined-plane design, consisting of two opposing wedges which move past each other by means of inclined, ball-bearing races. A precision leadscrew translates the lower edge horizontally, and this motion is converted into vertical translation by the inclined ball races between the two wedges. For automatic return to a pre-determined height, all UZM Series stages include a center home position. Position measuring is performed with a 2000 pts/rev. encoder, integral with the motor shaft. All UZM80 stages are equipped with a knurled knob for a manual control. For additional information, see Newport user manual at the link below. ftp://download.newport.com/MotionControl/Archive/Positioner%20Manuals/UZM_E.pdf Payments, Shipping, and Returns: We allow a 14-day right of inspection. Any return shipping must be by traceable and insured means. Buyer will be responsible for all shipping costs. Items are typically shipped within 1-3 business days following a cleared payment. We minimize buyer's cost by re-using shipping supplies and selecting the lowest rate service available. Buyer may request alternative shipping services, including overnight delivery when available. Multiple items will be automatically combined into a single shipment when possible. Pennsylvania residents pay sales tax. International buyers are welcome. All international payments must be made through PayPal. International buyers are solely responsible for import duties and/or brokerage fees. We offer low-cost shipping by USPS Priority Mail International when available. Please note that typical international delivery takes 2-4 weeks and there have been occasional delays of over 8 weeks. We are not responsible for shipment delays due to circumstances outside our control. If your purchase is time-critical, please select UPS Worldwide service or contact us for other available options.
