Nexus Ddr3 Dimm Slot Interposer For Tek Tla Logic Analyzers

US $1000

  • New Taipei City, Zhonghe County, Taiwan
  • Mar 3rd
Open on mobile:
QR code
DDR3-1867 DIMM Slot Interposer High Speed DDR3 Digital Validation Passive 240-pin DIMM Slot Interposer Supports all speeds of DDR3 up to DDR3-1867+ Passive 50% Module Reduction w/MR Technology™ Automated Logic Analyzer Setup DDR3 Protocol Violation Analysis Supports JEDEC PC3-15000, PC3-12800, PC3-10600, PC3-8500, and PC3-6400 DDR3 modules Supports Load Reduced LRDIMM This interposer is an extender design and does not require a dedicated DIMM slot. The logic analyzer connects above the normal DIMM height so that there is no mechanical interference with adjacent DIMMs. This is a passive interposer with no added buffers to conceal system performance. This Interposer has been designed to provide a quick and easy connection between Tektronix TLA7BB4 Logic Analyzer acquisition cards and a 240-pin DDR3 (Double Data Rate 3) bus. Datasheet from NEXUS web. This adapter was used for Intel platform DDR3 UDIMMs debug, using Tektronix TLA714 mainframe and TLA7AA4ES modules, 2 years ago.  After switching to DDR4 platform, no more need in this adapter. It comes as shown on photo, no DIMM installed, only adapter. It requires minimum one TLA7AA4 module and compatible TLA700/7000 series mainframe. Software package will be available for download to buyer without extra charge. It includes next TLA Support Packages: B_DDR3D_4A - requires four merged Tektronix TLA7BB4 acquisition cards each with the 1.4GHz state speed option B_DDR3D_2D - requires two merged Tektronix TLA7BB4 750MHz or 1.4GHz acquisition cards. R_DDR3D_2A (Reduced Module Count support) - requires two merged Tektronix TLA7BB4 750MHz or 1.4GHz acquisition cards. R_DDR3D_1A (Reduced Module Count support) - requires one Tektronix TLA7BB4 750MHz or 1.4GHz acquisition card. Shippins is via EMS Express from Taiwan. Usually it takes less than a week delivery time to USA.
“All cables and connectors clean and in working condition.”
Brand NEXUS
Model NEX-DDR3INTR-BB-TH
