Ni Pci-4461 National Instuments 24-bit, 204.8 Ks/s, 2 Inputs/2 Outputs Dsa Daq

US $1,850.00

Kossice, Slovakia
Jan 29th

Open on mobile:
QR code

NI PCI-4461 24-Bit, 204.8 kS/s, 2 Inputs/2 Outputs New, unused item, only PCI card in original pack 24-bit resolution ADCs and DACs with 118 dB dynamic range 6 gain settings for input ranges from ±316 mV to 42.4 V 2 simultaneously sampled analog inputs at up to 204.8 kS/s 2 simultaneously updated analog outputs at up to 204.8 kS/s Software-configurable AC/DC coupling and IEPE conditioning Variable antialiasing and anti-imaging filters and TEDS support Manufacturing price: $4200 More information The National Instruments PCI-4461 high-accuracy data acquisition module is specifically designed for sound and vibration applications. With 24-bit sigma-delta analog-to-digital converters (ADCs) and 24-bit analog output, it is ideal for stimulus-response applications including audio and structural tests. The NI PCI-4461 features 118 dB dynamic range and six gain settings for precision measurements with microphones, accelerometers, and other transducers that have very high dynamic ranges. Some common applications with the PCI-4461 include audio amplifier and production equipment test, shaker table control, vibration analysis, and machine condition monitoring. Best Value - Buy Both and Save The PCI-4461 is also available as a bundle with the NI Sound and Vibration Measurement Suite, which includes the NI Sound and Vibration Assistant, at a discount from the list price. See theResources tab for more information on the list of analysis capabilities in the Sound and Vibration Measurement Suite. Multidevice Synchronization for High-Channel-Count Systems You can synchronize the PCI-4461 with additional PCI-4461 boards to build systems with six simultaneous inputs and six simultaneous outputs (requires three PCI-4461 boards). In addition, you can synchronize other dynamic signal acquisition (DSA) boards, such as the four-input NI PCI-4462, with the PCI-4461 to create systems with 10 simultaneous inputs and two simultaneous outputs (requires one PCI-4461 board and two PCI-4462 boards). General Product Family Dynamic Signal Analyzers Measurement Type Accelerometer Voltage Form Factor PCI Operating System / Target Linux Real-Time Windows RoHS Compliant Yes Analog Input Single-Ended Channels 0 Differential Channels 2 Analog Input Resolution 24 bits Maximum Voltage Range Range -42.4 V - 42.4 V Sensitivity 5.05 µV Minimum Voltage Range Range -316 mV - 316 mV Sensitivity 37.7 nV Number of Ranges 6 Simultaneous Sampling Yes On-Board Memory 2047 samples Excitation Current 10 mA Dynamic Range 118 dB Signal Conditioning Anti-aliasing filter Current excitation Analog Output Number of Channels 2 Resolution 24 bits Maximum Voltage Range Range -10 V - 10 V Sensitivity 1.19 µV Minimum Voltage Range Range -100 mV - 100 mV Sensitivity 11.9 nV Update Rate 204.8 kS / s Current Drive Single 16.67 mA Digital I / O Bidirectional Channels 0 Input-Only Channels 0 Output-Only Channels 0 Counters / Timers Counters 0 Timing / Triggering / Synchronization Triggering Analog Digital Synchronization Bus(RTSI) Yes Physical Specifications Length 17.5 cm Width 9.9 cm I / O Connector BNC connectors SMB female

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	National Instruments
Country of Manufacture	Hungary
Model	NI PCI-4461
