Ni Pxie-4140 ,national Instruments 4 Channel Source Measure Unit (flex Smu) 4141

US $1,700.00

Kossice, Slovakia
Jan 29th

Open on mobile:
QR code

NI PXIe-4140, 4 Channel Source Measure Unit (Flex SMU) New, unused item, only PXIe card in original pack 4 SMU channels per single-slot, 3U PXI Express module ±10 V at ±100 mA output with 4-quadrant operation 100 pA current measurement sensitivity Continuous sampling of up to 600 kS/s Onboard hardware sequencing engine for triggering and synchronization MFG price: $5.000 More information The NI PXIe-4140 is a high-channel-count, high-speed source measure unit (SMU) with four identical SMU channels per PXI Express slot. Each SMU offers 4-quadrant operation to source or sink ±10 V at ±100 mA, and each channel has integrated remote (4-wire) sensing for accurate measurements. To help reduce measurement times and capture transient device characteristics, each SMU can sample up to 600,000 S/s. Additionally, source measure rates of up to 15,000 S/s allow quick I-V characterization of devices under test. For high-pin-count applications, you can load 17 NI PXIe-4140 modules in a single 19 in., 4U PXI chassis to provide a total of 68 SMU channels. A high-speed sequencing engine allows all of these SMUs to be synchronized with each other or with other instruments such as switches or high-speed digital test modules. General Product Family Power Supplies Form Factor PXI Platform PXI Bus Type PXI Express Part Number 781742-01 Operating System/Target Real-Time , Windows LabVIEW RT Support Yes Triggering SoftwareTrigger , ExternalTrigger , InternalTrigger External Clocking No I/O Connector 25-pin D-Sub Product Name NI PXIe-4140 Isolation Type Ch-Earth Ground Isolation Analog Output Channels 4 Resolution 18 bits Timing Hardware Update Rate 100 kS/s Current Drive Single 100 mA Current Drive All 400 mA Max Voltage -10 V - 10 V Maximum Voltage Range Accuracy 5 mV Maximum Voltage Range Sensitivity 100 µV Minimum Voltage Range -10 V - 10 V Minimum Voltage Range Accuracy 5 mV Min Voltage Range Sensitivity 100 µV Max Current Range -100 mA - 100 mA Maximum Current Range Accuracy 50 µA Maximum Current Range Sensitivity 1 µA Minimum Current Range -10 µA - 10 µA Minimum Current Range Accuracy 5 nA Min Current Range Sensitivity 100 pA Waveform Types DC Voltage and Current Readback Yes Total Power Output 1 W Output Quadrants Quadrant III , Quadrant II , Quadrant IV , Quadrant I Max Quadrants Per Channel 4

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	National Instruments
Country of Manufacture	Hungary
Model	NI PXIe-4140
