Nikon Ecliptic E200 Professional Microscope W/ 4 E Plan Lens look

US $480

Philadelphia, Pennsylvania, United States
Jun 16th

Open on mobile:
QR code

Up for auction is a Nikon Ecliptic e200 microscope with 4 E Plan Objective lens in good condition and working order. Unit functions great and smooth. The top does have a chip in the metal(picture) but not affect performance of unit and is secure. Very slight dust from storage but wiped down. Includes power cord and and vinyl cover. The top view lens is model E2-TB body with Nikon CFI 10x/20 eyeview. The E Plan lens's are 4x/.10, 10x/.25, 40x/.65, and 100x/1.25. Thanks for checking out auction and good luck bidding!! SPECIFICATIONS Optical System CFI60 Infinity Optical System, Parfocal distance: 60 mm Illumination High luminescent white LED illuminator (Eco-illumination) 6V20W/6V30W halogen lamp, Compliant multi-voltage (100 V-240 V) Eyepieces (F.O.V.) • CFI E 10x (20 mm) Focusing Coaxial coarse/fine focusing Right: fine Left: coarse/fine Focusing stroke: 26.5 mm Coarse: 37.7 mm/rotation Fine: 0.2 mm/rotation Coarse motion torque adjustable, Refocusing function Eyepiece Tube • E2-TB Binocular Tube Nosepiece Quadruple nosepiece (within main body) Stages Rectangular stage (within main body), with specimen holder, Cross travel: 78 (X) x 54 (Y) mm Objectives (NA / W.D., mm) • CFI E Plan Achromat 4X (0.10 / 30) • CFI E Plan Achromat 10X (0.25 / 0.7) • CFI E Plan Achromat 40X (0.65 / 0.65) • CFI E Plan Achromat 100X Oil (1.25 / 0.23) CFI Achromat DL and other higher-grade CFI60 objectives can be used. Condensers • E2 Abbe Condenser N.A. 1.25, Aperture diaphragm with position guide markings for respective CFI E Plan objectives • E2 Phase Condenser N.A. 1.25, Aperture diaphragm with position guide markings for respective CFI Achromat DL objectives Observation Methods Brightfield, Epi-fluorescence, Darkfield, Phase contrast, Simple polarizing Intermediate Attachment • E2-FM Epi-fluorescence Attachment, 2 filter cubes mountable • Y-THS Teaching Unit B (Side-by-Side) • Y-THF Teaching Unit (Face-to-Face) • Y-IDT Drawing Tube • Y-IER Eye-level Riser Power Consumption (max.) Normal value: 3 W (LED model), 41 W (halogen model) Weight (approx.) 7.3 kg (Binocular standard set) I Do Not End Auctions Early for Offers!!! Thank You for your interest!!!! Complete payment must be made within 3 days of placing your order (buy-it-now option) or winning your bid. Pennsylvania residents are subject to a 8% Sales Tax. We will ship the package only after the payment has been verified and cleared. We can only ship to the address we receive from PayPal. We cannot ship to any address you give us over the phone, email or eBay message. Please make sure you choose the correct address when you make the payment. We will not be able to change the shipping address after payment is made. If you have any questions please call us before paying and we will be happy to help. I will not end an auction early unless "Buy It Now" option was applicable. Serious bidders only. I ship promptly to confirmed addresses anywhere in the Continental U.S.A only!!! My shipping rate is flat and for swift shipment I accept Paypal only. Thanks Once Again and happy bidding!!!!!!!!
