Nitek Cxm22 Video Balun Utplinks Crossover Card

US $25.00

Mansfield, Ohio, United States
Jan 30th

Open on mobile:
QR code

Pro-Security Equipment Supply Description Another great bargain brought to you by: Pro-Security Equipment Supply Product Description The CXM22 crossover insertion cards are designed for use with the CX452 modular card cage (sold separately). These units are components of the Nitek UTPLinks video, data & power twisted pair system. The CXM22 crossover cards are unique unshielded twisted pair (UTP) transmission products designed to operate with TIA/EIA standards-based network cabling. The cards plug into and are powered through the CX452 modular card cage. The CX452 is a 1 RU card cage that holds up to 5 of the crossover insertion cards. Power is supplied from a separate PS115 power supply (sold separately). The crossover system and power supply are typically located in an IDF (telecom) closet. There are three card models available and any of the three can be plugged into the card cage in any combination. Each card is designed to accommodate 4 cameras. The primary function of each of the cards is to provide a means of interfacing copper backbone cables to horizontal cable runs and inserting voltage to the individual camera and/or P/T/Z over the horizontal run. In addition, models of the cards are available that provide RS422 distribution and/or video transceivers. Using a single standards-compliant 4-pair UTP category 5 or better cable, video, data and power can be sent up to 100 meters to a fixed or P/T/Z camera. Features Three available plug-in cards provide flexibility - any combination of three crossover cards can be used in any of the CX452 card cage slots Plug-in cards also provide future system expansion or features modification Each of the cards cover 4 zones with separately fused outputs One 4-pair category 5 cable can be used for video, RS422 and 24 VAC Detection LED’s for power (all cards) and RS422 (CXM22 & CHM22) TIA/EIA 568B compatible Wire and Cable Recommendations On horizontal runs with fixed cameras (applications up to 8 watts/port) category 5 or better; 22 AWG or 24 AWG. For P/T/Z camera (applications >8 watts/port) category 5 or better; 22 AWG is recommended. In the case of backbone cable 24 AWG category 3 or better is recommended. Multi-pair cable with an overall shield is acceptable. While signals may be routed through 66 blocks or 110 blocks, any bridge-taps, also called T-taps and any resistive, capacitive or inductive devices MUST BE removed from the pair. For more specific information regarding wire types, gauges and proper installation techniques, please call (800) 528-4343 for technical assistance. OVERSTOCK SPECIAL! NEW NEVER USED UNITS, SEE MY OTHER AUCTIONS FOR MORE SECURITY OVERSTOCK DEALS YOU CAN'T PASS UP.
