Nixie Clock Kit W/dekatron Control - 9vac In - Board Only (rev D)

US $14.95

Lawndale, California, United States
Jan 29th

Open on mobile:

Six Digit Nixie Clock Kit with Dekatron Pendulum Control - Bare Board Only In kit form, you get a circuit that is a six digit nixie clock, plus has additional circuits to run a dekatron. 9VAC are the preferred input voltages. Up to 11VAC, or as low as 7VAC acceptable. The current draw varies on the type of nixie tube you use, but 1 amp is the absolute minimum. A 2 amp wallcube maybe needed if you're driving IN-18s. A 5.5mm OD x 2.5mm ID power jack is provided, so wallcubes. A HV switching supply is needed to generate the 170V, to power the nixies. This supply is not provided, so you need to get this elsewhere. A Taylor 1363. can fit in J5, or my dual supply in J4. Here's a link to all the instructions you need to build this kit, once you receive it: Clock Kit. Nixie tubes dekatron are to be acquired separately, by the buyer. There are many sources available, both on eBay, and elsewhere online. The boards do not mount directly the tubes. Connector locations are provided for hours, minutes, seconds, and dekatron groups. This way you are not limited to certain particular types of tubes. This is the third release of this board, Rev D (No Rev B). It has a considerable number of parts, and uses discrete CMOS logic. It could have been made less complex, part-wise, if a pre-programmed microcontroller was used. By using several logic chips, it makes it more understandable by the casual electronics hobbyist. No board cutting is required, as was in the prior release. However, an additional resistor is required and is covered in the instruction link, above. Here's a video of the clock running. Again - This is the bare board only - Revision D, no cuts required ! The difference between Rev D, over Rev C, is that pads are now added to the board for R45 & R46. On the older Rev C, these two resistors had to be tacked on the back of the board, "after-the-fact". As of August of 2014, this will only be sold as a bare board, and not a complete kit. The Russian 74141 chips have been creeping up in price, and their availability is diminishing. They are still readily available, but in bulk, at twice the cost from when I first sold this kit. I may still release as many as 5 as a complete kit (pay attention to my other listings). I am in the process of designing a new clock kit, using domestically available parts. . Board measures 6.25in x 2.6in (159 x 66mm). Shipping Weight: 5 oz Items shipped to your eBay registered address (not Paypal's). Contact me using eBay's messaging system. I DO NOT read my email. Its used only as the Paypal payment link. Domestic shipments automatically have "Delivery Confirmation", which essentially is a tracking method. International shipments will only have their "Customs Declaration" number listed, unless the foreign buyer chooses "Registered Mail". With "Registered Mail", the package can be tracked. "Registered Mail", will incur and additional $12.00 US to the total cost. If you want this option please contact me and wait to be invoiced. If you just pay for it (without being invoiced), the item will be shipped without tracking. eBay only required that I (the seller) prove that I shipped it. A "Customs Declaration" will satisfy that requirement. Its your nickel. From NOW ON, if its lost and you DID NOT pay for registered mail, then THAT'S IT ! IN SOME EURO COUNTRIES, EXPECT A DELAY OF CLOSE TO 2 MONTHS. IF THIS IS NOT ACCEPTABLE YOU DON'T HAVE TO BUY FROM ME ! BUT ITS YOUR BUREAUCRATIC CUSTOMS AGENCY'S FAULT. I CAN INSIST ON SHIPPING BY REGISTERED MAIL. THEN AT LEAST YOU CAN TRACK THE PARCEL !!! Please pay or contact me about payment within three days after the end of the auction. Paypal preferred. Domestic buyers contact for other payment methods. Paypal ONLY from foreign buyers. If you are sending your payment thru the mail, please email me that you are doing so. I have recently cancelled my mental telepathy services, so I can no longer read your minds.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Tortugascuba
Country of Manufacture	United States
Model	N6D
