Non-programmable Digital Slab Sensing Thermostat For Hydronic Radiant Floor

US $79.90

Ontario, Canada
Jan 29th

Open on mobile:
QR code

D-508F: NON-PROGRAMMABLE DIGITAL SLAB SENSING THERMOSTAT FOR HYDRONIC RADIANT FLOOR HEATING D-508F digital non-programmable hydronic radiant floor heating heat only thermostat is designed to control either ambient(air) temperature (A Mode) or floor temperature (F Mode) or a combination of ambient temperature with floor temperature limits(AF Mode). An auxiliary remote sensor is provided to measure slab temperature in order to control the floor temperature(within maximum and minimum limits in AF Mode). It can also be used for sensing the outdoor temperature in A Mode. FEATURES: Large LCD display Easy-to-Read Digital Multi-Display with backlit which provides constant readout of two sensor temperatures(eg. ambient and floor) and setpoint simultaneously, functional status and control settings. Three temperature control modes: A Mode : controls ambient temperature F Mode : controls floor temperature. Also displays current ambient temperature. AF Mode: controls the ambient temperature and maintains the floor temperature within the desired minimum limit for floor warming and maximum limit for protecting floor coverings. Also, displays current floor temperature. QuickSet feature allows instant setpoint adjustment without entering the SETTING mode Contemporary design Easy installation and setup Selectable display in °F or °C On/Off switch to shut off relay output or shutdown the thermostat at end of heating season for added security EEPROM memory retains control settings in the event of a power failure Lockout mode to prevent tempering by unauthorized personnel Sensor failure and out of range indications One stage heating application Backlit option: Auto (60 sec.)/OFF/ON Supplied with new P-05 10 ft. floor sensor Battery free RoHS(Restriction of Hazardous Substances) compliant means this thermostat is Eco- friendly SPECIFICATIONS: Display Format: Liquid Crystal Display(LCD) with backlit Power Input : 24VAC ±10%, 50/60Hz, 0.5VA Contact Rating: 2A 24VAC Selectable display in °F or °C Setpoint Range (ambient): 34-100°F(1-38°C). Default setting: 70°F (21°C) Floor Temperature Control Range: 34-122°F(1-50°C) Default setting: 82°F (28°C) Maximum Floor Temperature Limit(AF Mode): 35-122°F(2-50°C) Default: 82°F(28°C) Minimum Floor Temperature Limit(AF Mode): 34-121°F(1-49°C) Default: 40°F(5°C) Temperature Display Range: -22 to 131°F(-30 to 55°C) Switching Differential: A/F/AF Mode: 0.5/1.0/1.5/2°F(°C), Default: 1°F/1°C Sensor Probe: P-01 10k? thermistors, 10" lead, 3/8"(9.5mm) OD x 13/16"(20.6mm) length Operating Temperature: 32 - 122°F (0 - 50°C) Dimension: 3.62"W x 2.99"H x 0.91"D(92 x 76 x 23mm) Weight: 0.32 lb. (145 g) Storage: -4 to 120°F (-20 to 50°C) Material: Flame retardant plastic Please click to go to Azel's product page for brochure and wiring diagram

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Azel Technologies Inc.
MPN	D-508F
Model	D-508F
Country of Manufacture	Canada
