Nordson-efd 325 Ultra Tt Automated Dispensing System

US $11,392.71

Phoenix, Arizona, United States
Jan 30th

Open on mobile:
QR code

Click Here. Double your traffic. Get Vendio Gallery - Now FREE! Nordson-EFD Ultra TT 325 Automated Dispensing System Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from Nordson-EFD and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This unit came directly off the bench at the factory. The main system is guaranteed to work. The PDA doesn't sit in the dock very well. The unit has various different consumables for 10 CC and 3 CC syringes and barrels. The Unit's Serial Number Tag Reads: Model Number: 325 Ultra TT Serial Number: EF30779 Power Requirements: 100-240 VAC~, 5 A, Single Phase, 50-60 Hz Date Manufactured: 1/07 CE Marked: Yes PDA Software/Firmware Version: 1.2 (not currently installed on the PDA but the CD is included for it) Link to the Datasheet: EFD Ultra-325 & 525 TT Series Dispensing System Datasheet Link to the Quick Install Guide: EFD Ultra-325 & 525 TT Series Dispensing System Quick Install Guide Link to the Manual: EFD Ultra-TT Series Automation Dispensing System Manual Ultra-TT Key Features: Fully integrated positioning and dispensing functions. Easy programming with the Palm handheld. Height sensor for critical deposit control. Description: The Ultra TT Automation Series combines precision dispensing and accurate positioning functions into one fully integrated, compact tabletop unit. For manufacturers, the easy programming of the Ultra TT Series - combined with closed-loop servo controls and powerful drive moters for fast, accurate positioning - means higher productivity, greater process consistency, and less scrap and rework. Ultra 325TT Specifications: Work Area: 325 (X) mm x 325 (Y) mm x 100 (Z) mm Resolution: 10 µ Repeatability: 25 µ Max. Speed: 500 mm/sec Acceleration: 0.25 g Mechanical Configuration: H-Bridge De-coupled Axes Control Method: Closed Loop DC Servo Drive System: Cable Drive Footprint: 560 mm W x 670 mm D x 750 mm H (does not include accessories and the dispensing system) Weight: 45 kg Tool Payload: 5 kg Work Piece Payload: 10 kg Programming Interface: Front Panel Buttons, Palm Handheld Program Capacity: 100 Point Capacity: 10,000 Theta Axis: Upgradeable from the factory General Purpose I/O: 16 inputs / 16 outputs Discrete I/O: 1 analog input / output, 4 inputs / 4 outputs, 2 solenoid drivers External Communications: 1 RS232 / 1 Pal Height Sensor: Yes (Standard) Tip Change Reset: Yes (Standard) Software Compatibility: Palm OS 4.0 or higher Current Consumption: 320 Watts Input Voltage: 100 VAC ~ 240 VAC (±10%) Dispense Controller: Integrated Number of Dispense Valves/Syringes: 1, 2 or 3 Patterns: Lines, Circles, Arcs, Continuous Paths, Potting and Dots Dot / Line Types: 10 Dots / 10 Lines per program Front Panel Control: Offset, Jogging & Program Select For More Pictures Please Click the Following: Picture 2 - Front View Picture 3 - Back View Picture 4 - Right Side View Picture 5 - Left Side View Picture 6 - Z-Axis Dispensing Mount Picture 7 - Sample Stage Picture 8 - Main Controls Picture 9 - Interfaces & Facility Connections on the Back Picture 10 - PDA Picture 11 - Serial Number Tag $100.00 minimum for packaging, handling, and order processing. Shipping to be determined by destination. If you have any questions please email us at: ebay@mhzelectronics.com or call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 08/09/11 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
