Home Q&A Payments Buyer Protection About us Contact us Store search Store category You may also like Normally Open 1/2" NPT AC220V-240V Electric Solenoid Valve for Gas Water Air Product Description Specification: Size:3/4" NPT Coil Voltage: AC220V-240V Valve Type: 2 Way Normally Open (Valve closes with energized) Service Media: Air, Gas, Liquid, Vacuum Operation Model: Direct Lift Diaphragm Body Material: Brass Seal Material: NBR (Buna N) on Diaphragm and Plunger Tip Operating Pressure: Vacuum to 90 PSI Operating Temperature: NBR -10 to 80 °C Voltage Tolerances: DC: +10% –5% ; AC: +10% -15% Product Features •Working Pressure: 0-5 Bar (0-71 psi) - Closes at Zero Pressure / No Fluid Pressure Requried •Brass Body, NBR (Nitrile Rubber) Seals, Temperature Range: -5C - 80C (29F - 176F) •NEMA Protection Class: IP65, Warranty: 1 Year, Orrifice Size: 10mm , CV Value: 0.6 •Lifespan: ~200,000 Switches, Wiring Connection: DIN Connector: easy to install wiring terminal •Suitable for water, hot water, gas, air, noncorrosive oils & Vaum Description A two way solenoid valve means that there are 2 ports in which fluid flows from/to. The Direct Acting valves will stop flow in either direction, but are still only designed to allow full flow in a single direction. Semi-Direct acting valves require assitance from fluid flow to open. These 2W valves open/close with a 0 psi working pressure. However, while they do not require pressure from the working fluid to remaing open or remain closed, the semi-direct lift valves do require some assistance from the fluid for the initial opening/closing. Some gravity flow applications may have trouble overcoming the static friction of the seals within the valve while initially opening or closing. General purpose 2-way direct acting and semi-direct lift acting valves. Common applications include water, oil (below 20cst), air, gas, freon, *vacuum, weak acids & weak alkali. Check chemical compatibility charts for the valve body and seals of the valves to see if they are compatible in the case of using a weak acid/base. *Only Solenoid valves of 1" ports and smaller are able to operate with full vacuum. Available in a body/seal material of brass/NBR or stainless steel/viton. Brass/NBR valves are suitable for water, hot water, gas, air, non-corrosive oils and freon. Stainless Steel/Viton valves are suitable for hot water, weak acids, weak alkali, chemical salt, oils and hydrocarbons such as *Diesel Fuel. *Diesel fuel is compatible with Brass/NBR, however, it is known to slightly shrink NBR and with any small shrinkage of the material in the diaphragm, it can cause a solenoid vale to cease in operation. For this reason, we only warranty the stainless steel/viton valves for diesel fuel and similar applications. Flow of the Valve The Semi-Direct Lift valves will partially open or close from activation, and require fluid assitance to prop open or closed. They can only stop flow in one direction, which is indicated by the arrow on the body of the valve. If pressure is applied in the opposite direction, the valve will be opened and allow a slow trickle of fluid in the opposite direction. These valves should only be used for stopping flow in one direction. If preventing of backflow is required, a check valve should be placed in the line after the solenoid valve. Direct acting valves switch on their own with no fluid assitance and can block fluid flow in both directions. Electrical Connection The electric coil uses a DIN connector. This connect contains wiring terminals for easy connection and a simple connect/disconnect: Simply unscrew the DIN connector and unplug the valve for service (no need to disconnect the wires from the terminals). The coils are not polarized, which mean that positive/negative does not matter when wiring them. We highly recommend using the ground terminal in the DIN connector to avoid electric shock when touching the valve. Coil Use The coils are designed to withstand heat build-up from continuous use as long as they are exposed to ambient and not insulated in order to dissipate heat. Although they can be used continuously without shutoff, it will reduce the life of the coil to operate them constantly. DC valves will experience more rapid heating than AC valves due to the higher amperage required to operate them. The rated maximum power consumption often only occurs when the valve operates near the maximum pressure. When no pressure is applied, the valve's power consumption is about 1/3 of the maximum power consumption. Limitations of the Larger Valves For the larger valves (1-1/4" and up), when operating near the maximum pressure, it can take a little longer for them to close than the smaller valves. Because of this, some applications with larger valves may also experience a "fluttering" sound as the valve tries to close against the high pressure. Valves larger than 1" cannot hold a full vacuum. It is recommended to use the smaller valves for vacuum applications, especially if near full vacuum needs to be achieved. Working Fluid The working fluid can be a variety of substances. The fluid must be clean of debris for proper operation of the solenoid valve. If any debris gets into the valve body, it can clog the diaphragm from a complete seal, thus preventing a a successful closure of the valve. In the event of clogging, these valves are easy to clean. Simply remove the 4 bolts holding the body together to access the diaphragm for cleaning. Q&A Payments Buyer Protection About us Contact us Q&A Q.When Can I get this item? A.The Item Usually Shipping By Air Mail, Estimated Delivery Time is 7~60 Days. Q.Does The Price Include Import Tariff? A.No, The Import Tariff will be pay by buyer when delivery the item. Q.Do You Offer Express Shipping Method? A.Yes, And If the item More Than 3Kg, We Usually Shipping it By Express. Q.Where is the item Location? A.China. And Some of item we have it in Germany, United Kingdom & United States Warehouse. Payments 1.Please pay within 4 days after auction. 2.Please tell me if you want to cancel the order before eBay open unpaid case. Buyer Protection 1.Item not as description? Keep it! We issue full refund. 2.Item does not work? Keep it! We issue full refund. 3.Item's working life is too short? Keep it! We issue full refund. 4.Please Give us a chance to do something above before you want to open a dispute or leave a negative feedback. About us We're concentrate on Motorized Ball Valve, Circulation Pump, Solar Powe Pump. We Have Warehouse From Germany, UK, USA, Can Help With Buyer Get The Item As Soon As Possible and Save Import Charge. Contact us All communication is handled through emails and ask a question. We strive to answer all emails as quickly as possible.
