Norton Assa Abloy Parallel Arm Door Closer, 36"/30" Door, Non-Hold Open Norton P8503 Architectural Door Closer Parallel Arm Backcheck/Reversible Spring Adjustment Gold Finish Features • Exceeds 10 million cycles (witnessed and verified by UL) • Non-handed • Staked valves • Standard, separate and independent, latch, sweep and backcheck intensity valves • Cast aluminum body • Rack-and-pinion design • 1-1/4" (32mm) diameter piston • 5/8" (16mm) diameter pinion journals • 2-1/8" (54mm) projection (standard covers) • All standard arm applications (with slim, full or metal covers) allow doors to swing 180 degrees, conditions permitting • 8500/8501 - shipped with full plastic cover • Full size template • 25-year limited warranty Compliance Standards • ANSI/BHMA A156.4, Grade 1 certified • UL listed • UL10C compliant for positive pressure • ADA compliant (8301 and 8501) Typical Applications Recommended for interior or exterior doors including: • Offices • Banks • Retail Malls • Hotels • Health Care • Clinics Parallel Arm This application provides the most appealing design appearance for a surface-mounted door closer having a double lever arm. This also makes it beneficial in vandalism-prone areas. It is on the push side of the door and the arm assembly extends almost parallel to the door. In the closed position, there is very little or no hardware projecting beyond the frame face in most situations. Due to the geometry of the arm it is approximately 25% less power efficient than a regular arm application. The entire closer and arm assembly are mounted below the frame stop. Top rail clearance dimensions will vary based on the type of cover used. (See pg.15) Non-Hold Open Self-closes door every time door is opened. Auxiliary stop (by others) required. Closer Series: 8500 Covers: Full Plastic R Minimum Top Rail W/O Drop Plate: 5-1/4" (133) With 8148, 8158, 8548, 8548A Drop Plate: 3" (76) S Minimum Top Rail Clearance: 6-1/4" (159) U Closer Length: 13" (330) V Closer Height: 2-7/8" (73) W Arm Extension: 8" (203) Door Widths Inches (cm) Interior: 36" (91) Exterior: 30" (76) Non-Hold Open Features Aluminum Alloy Housing Closer bodies are constructed of a special aluminum alloy, carefully selected to accommodate interactive steel components and operating conditions. Rack & Pinion Operation Provides a smooth constant control of the door through its full opening and closing cycle. 180° door swing can be achieved when door, frame, hardware and arm function do not interfere. Non-handed With few exceptions all series 8300/8500 and series 8301/8501 door closers are non-handed and can be installed on either right- or left-hand swing doors. Pinion shaft extends vertically through the closer body in both directions. Some options, as noted on pages 6-7, will require that the hand of the closer be specified. Sweep Speed Control Valve Allows adjustment of door speed from the door's full open position down to approximately 10° from the closed position. Latch Speed Control Valve Allows adjustment of door speed from approximately 10° down to the door’s fully closed position. Tri-Style® 8301/8501 comes with screws, brackets and soffit plates to allow for regular, top jamb, and parallel arm installations. Adjustable Backcheck Valve Provides control of the door in the opening cycle, beginning at approximately 75° of door opening. It cushions the door opening when the door is forcibly opened beyond its pre-adjusted limits. Standard Molded Covers Molded of high-impact U.L. listed material. These covers are non-handed for all applications. Warranty Limited 25-year warranty for defects and life of the building on the aluminum housing. Closer Fluid NorGlide® closer fluid is a specially formulated multi-viscosity hydraulic fluid that contains lubricity and anti-oxidation agents that provide optimum performance and efficiency. This fluid complements the interaction of the door closer's aluminum housing with its steel and brass components, while maintaining stable viscosity to allow the door closer to perform in temperatures ranging from extremely high to as low as -40° F. Door Closer Power Options Series 8300/8500 Sized Door Closer Available in five different power sizes (2, 3, 4, 5 or 6). Each power size is adjustable up to 50% stronger than the minimum closing force for that size; as outlined in ANSI/BHMA standard A156.4 option PT 4C. Closers will also comply with the opening force requirements as outlined in the Americans with Disabilities Act (ADA) and ANSI/BHMA standard A117.1 for interior doors. Suggested Application: 8300/8500 Series Closers for interior and exterior doors shall be full rack-and-pinion type with cast aluminum alloy shell. Closers shall be surface mounted and shall project no more than 2-1/8" from the surface of the door with standard cover. Closers shall be non-handed to permit installation of doors of either hand. Closer fluid shall contain lubricity and anti-oxidation agents. Closer fluid shall maintain stable viscosity to allow door closer to perform in temperatures ranging from extremely high to as low as -40°F. Closers shall have power adjustment to permit a 50% increase in power over the minimum closing force for any size. Closers shall have two non-critical valves, hex key adjusted, to independently regulate sweep speed and latch speed. Closers shall have adjustable backcheck intensity controlled by a hex key adjusted valve. [Closers shall have adjustable delayed action closing controlled by a hex key adjustable valve.] Regular arm and top jamb closers shall have a non-hold open shoe permitting 15% (+ or – 7-1/2%) power adjustment.** Closers shall be enclosed in a [molded resin cover] [plated or sprayed metal cover], Closers to be Norton [8300/8500] [8500M] [8500A] [8500MA]. **For special arms insert that specification here (see column three on this page). Any offer of free shipping is based on the cheapest rate at time of shipping regardless of any shown option. Expedited shipping and 24-hour handing available. Return Policy I do my best to research the parts and their compatibility. If I make a mistake in the listing or shipping I will refund the price and pay shipping both ways or just refund your money depending upon the cost to me. If you make a mistake and want to return it, you pay shipping both ways. Plus, I reserve the right to charge a return fee of 20% of the item's cost ($5 minimum to a maximum of $25), to cover my fees and time. A Note on Fees & Best Offers Please be mindful of my cost of doing business when submitting a price for Best Offers. More often than not shipping costs are greater than any profit I make. eBay charges 10% on the total price including postage. PayPal charges 3% + $.30 My Goals 1. To operate with integrity so that you can be assured of anything I have for sale. 2. Happy customers assure potential customers that I mean what I say. 3. Make enough money to make it worthwhile. This is not my main occupation but I do take pride in my customer service and giving the buyer a good value. If you have any questions or comments just let me know. The Fine Print Don't drive and text • Eat your vegetables • Save for a rainy day Check the air in your tires • Say thank you • Admit your mistakes Call your mother once in a while.
