Noyes M700 -20 Compact Single-mode Otdr

US $7,375.00

Mansfield, Massachusetts, United States
Jan 29th

Open on mobile:
QR code

M700-20 Single Mode - 1310/1550 Noyes Compact OTDR (WE TAKE TRADE-INS. IF YOU HAVE ANY EQUIPMENT YOU NO LONGER USE, TAKE IT OFF THE DUSTY SHELF AND TURN IT INTO A CASH TRADE-IN - $500 minimum guaranteed) The Noyes M700 from AFL Telecommunications is a compact, full featured, single-mode OTDR that includes an integrated Visual Fault Locator (VFL), an Optical Power Meter (OPM) displaying up to three wavelengths simultaneously, and a large transflective touch screen display suitable for both indoor and outdoor operation. The M700 OTDR supports Real Time, Full-Auto, and Expert (manual) modes, precision event analysis, dual-wavelength testing, rich file naming, and an intuitive job set-up functionality. In addition to OTDR event analysis, pass/fail acceptance values, and marginal warning, specific values can be set to alert the test operator of failing or marginal events. Using one of the Least Squares Approximation (LSA) loss methods, events may be added or deleted manually. Thousands of OTDR and OPM test results can be stored internally or on the supplied USB drive, and are transferable via a USB cable or drive to a computer for viewing, printing and analyzing with supplied Windows® compatible software. Saved OPM loss values for a cable in one or two directions can be displayed in a table on the M700 for evaluation and comparison. With short dead zones, a dynamic range of 40/38 dB, and greater than 8-hour battery life during continuous testing, the M700 is perfect for testing optical fibers in service provider metro areas. Features: • 40 / 38 dB dynamic range @ 1310 / 1550 nm • Integrated Optical Power Meter (OPM) and Visual Fault Locator (VFL, 650 nm) • LSA Measurements and manual events in Expert mode • Pass/Fail Event and Link Thresholds settings • OTDR results saved as industry standard (GR-196) .SOR files • OPM stores results and displays up to three wavelengths simultaneously • Large, high bright, sunlight readable, transflective touchscreen • Tool-free, switchable adapters (SC/FC/LC) • Integrated fiber launch ring holder • 2 USB host ports • USB drive and Windows® compatible software included Specifications OTDRSpecifications Emitter Type Laser Safety Class Class 1 FDA 21 CFR 1040.0 & 1040.11 Center Wavelengths 1310/1550 nm Dynamic Range (SNR = 1) 40 / 38 dB (1310/1550 nm) Event Dead Zone 1 0.8 m Attenuation Dead Zone 2 4.5 m Pulse Widths 5, 10, 30, 100, 300 ns, 1, 3, 10, 20 ms Range Settings 250 m to 256 km Distance Sampling Points max. 64,000 points Data Point Spacing 0.125 m Group Index of Refraction (GIR) 1.4000 to 1.6000 Distance Uncertainty (m) 3 ± (1 + 0.0005% x distance + data point spacing) Trace File Format Bellcore GR-196 Version 1.1 Trace File Storage Media Internal flash memory USB flash drive Downloadable from OTDR directly to PC Trace File Storage Capacity Internal 1000 fibers Data Transfer to PC USB OTDR Modes Full Auto, Real Time, Expert Tool Free adapters Modular cleanable SC/ST/FC/LC Visual Fault Locator Specifications Emitter Type Laser Safety Class Class II FDA 21 CFR 1040.10 & 1040.11; IEC 825-1:1993, EN60825-1:1994 Wavelength 650 nm Output Power (nominal) 0.8 mw Power Meter Specifications Calibrated Wavelengths 850, 980, 1310, 1490, 1550, 1625 nm (displays up to 3 simultaneously) Detector Type Filtered InGaAs detector Measurement Range (dBm) +26 to -50 dBm Accuracy 4 ±0.25 Measurement Units dB, dBm, mW Wavelength ID 5 Yes Set Reference Yes Data Storage Yes Tone Detection 270 Hz, 330 Hz, 1 kHz, 2 kHz General Specifications Size 27.4 x 19.3 x 7.1 cm (10.8 x 7.6 x 2.8 in) Weight 2.3 kg ( 5 lb) Operating Temperature -10 to +50°C, 0 to 90% RH (non-condensing) Storage Temperature -20 to +60°C, 0 to 90% RH (non-condensing) Power Rechargeable Li-Ion or AC power adapter Battery Life 6 > 8 hours continuous OTDR testing Recharge Time 7 4 hours Display 6.5 inch (16.51 cm), color, transflective M700 SM OTDR 1 $7,795.00 M700 SM OTDR w/ Hard Case, Charger, Spare Battery 1 $9,495.00 M700 SM OTDR w/ Hard Case & OFS300-200C 1 $9,595.00 We rent and 'lease to own'. We take trade-ins too. Visit our Noyes Store - www.TamgeStore.com www.TamgeStore.com . Warranty: This brand new unit comes with a full 1 year Noyes factory . 24 Hour delivery available to job site Powered by eBay Turbo Lister
