Nrc Newport Esp Esp300 11n111 V3.09 2 Axis Controller Tested Working

US $1,500.00

Cambridge, Vermont, United States
Aug 20th

Open on mobile:
QR code

THIS IS A USED, TESTED, WORKING, NEWPORT ESP 300 / 11N111 VERSION 3.09 DUAL AXIS MOTION CONTROLLER WITH PDF MANUAL THE FOLLOWING INFORMATION IS FROM THE NEWPORT ESP 300 LITTERATURE: Technology: The ESP300 uses a 32-bit, floating point, DSP processor for high precision synchronized control. A digital PID-FF (feed-forward) servo loop ensures precise velocity profile tracking and accurate positioning. A 1000x programmable microstep resolution provides ultra-smooth low-speed stepper positioning capability, and 18-bit DC motor command output ensures improved stability for precision applications Motion: The ESP300 provides several modes of positioning including synchronized and non-synchronized point-to-point, jogging, linear or circular interpolation, and continuous path contouring. With electronic gearing, any axis of the ESP300 can be “slaved” to any other axis, even if they have different motor/gearhead ratios or lead screw pitches. Other sophisticated motion features include on-the-fly position, velocity, or trajectory changes for complex motion and alignment routines. Software limits can be set to improve systems safety. An advanced origin search routine includes encoder index pulse consideration for precision homing. Backlash and linear error compensation eliminate repeatable system errors. Inputs/Outputs: 16 bi-directional digital I/O can be user programmed as either inputs or outputs for internal or external event synchronization. When configured as inputs, they can be used to execute a program or to stop a motion. When configured as outputs, they can monitor the status of a motion to provide a hardware interface for external equipment. An additional watchdog timer and remote interlock are supplied as an invaluable safety feature. Programming: The ESP300 makes programming complex motions easy using a powerful programming language with over 100 commands. Each ESP300 features a standard RS-232-C communication link for easy computer interfacing. An optional IEEE-488 (GPIB) interface is available for high speed parallel communication. 64kB Flash non-volatile user program memory allows for storage of to 100 user-defined programs for computer independent usage. A complete library of LabVIEW™ drivers covering all ESP300 commands and communication DLL’s for all most popular Windows versions are available and get constantly updated through our website at www.newport.com. Powerful software utilities reduce start-up time and support application development. Auto-Configuration: When used with ESP compatible motion devices, the ESP300 motion controller will automatically configure itself providing true plug-and-play compatibility. PID parameters, motor types and gear ratios are automatically set for you at power up—there are no PID or gear factors to set. The ESP300 can also be configured to operate non-Newport stages that fit within driver module specifications. Options: ESP300 options include a user-friendly front panel interface providing an intuitive menu system from which you can execute motion programs, initiate manual moves, and configure operating parameters. A hand-held keypad allows local programming and a digital joystick or trackball can provide convenient jog control. PAYMENT AND SHIPPING TERMS: THE BUYER MUST MAKE CONTACT WITHIN 24 HOURS OF AUCTION END TO ARRANGE PAYMENT AND SHIPPING. PAYMENT MUST BE RECEIVED WITHIN FOUR DAYS OF AUCTION CLOSING. THIS SET WILL BE SHIPPED FOR FREE VIA FED-EX GROUND SERVICES TO ANY LOCATION WITHIN THE "LOWER" 48 STATES ITEM WILL BE SHIPPED WITHIN 2 BUSINESS DAYS OF PAYMENT BEING RECEIVED FROM "EBAY MANAGED PAYMENTS" ACCEPTED METHODS OF PAYMENT: BUSINESS CHECK, CASHIERS CHECK, PAY-PAL OR BANK TO BANK WIRE TRANSFER. ***THIS ITEM IS SUBJECT TO PRIOR SALE, ALL "BEST OFFER" SALES ARE "AS-IS" ***

“TESTED / WORKING W/ PDF MANUAL”

Model

ESP300

MPN

Does Not Apply

Country of Manufacture

United States

Brand

NEWPORT
