Nsk Nakanishi Astro-e6040 Control & Nsk Ems-6040 Spindle Motor

US $800

U.S.A, United States
May 26th

Open on mobile:
QR code

NSK NAKANISHI ASTRO-E6040 BRUSHLESS MOTOR CONTROL & NSK EMS-6040 SPINDLE MOTORThe high-frequency spindles” are sophisticated products with the highest precision, stability and running smoothness. HIGH POWER SOLUTIONS E6040 SERIES ELECTRIC SYSTEM COMPLETE SET Outside Diameter 2.36" ( 60 mm) High-speed rotation, high-precision and high-power brushless DC motor/spindle of 2,000~40,000 min-1(rpm). High-power 600W brushless DC motor spindle with an external diameter of 2.36"( 60 mm). Maximum cutting tool shank diameter of 1/4"( 6.35 mm) can be used. Ideal for use on special purpose machines, NC lathes, robots, etc. for small diameter end milling, drilling, slitting, chamfering, grinding, etc. EMS-6040K has a great flexibility of motor cord which is suited for robot attachment. Collet Nut (CHN-B) For Collet (CHK) Rated output 400W (Max. output 600W) Spindle accuracy 1 m or less. Achieved continuous run of over 5,000 hours. Extremely low vibration brushless DC motor. Utilizes a double pair of ultra-precision ceramic bearings to obtain high rigidity in both radial and thrust directions incorporates 2 ceramic bearings on the front side and 2 on the rear side. External housing made of precision ground stainless steel SUS-416. Include : NSK NAKANISHI ASTRO-E6040 Brushless Motor Control Unit (Model NE-123) (220-240 VAC) 2 NSK EMS-6040 Spindle Motors Toroid Isolation Transformer (convert 120VAC to 240 VAC) DATEX -OHMEDA Air Compressor (120 VAC) 2 Collet (CHK-3.175) for cutter bit 1/8" , Wrench and Power cables Tested run ,very quiet, smooth and powerful working condition There are some minor scratches , scuff , dings due to normal used previously Sold and come as photos , ( one spindle motor is missing a c ollet nut) Item will be palletized or crated for shipping Buyer are responsible to arrange for freight to ship it or welcome to pick up in Virginia 20111 TERMS OF SALE: •Only what is shown in the eBay photo and mentioned in the listing is included, anything else should be understood to not be included. • For sale is for the eBay item only, no service or tech support are included, but if you have a question feel free to ask and we'll answer if we can. • Please understand that this is an auction/liquidation environment, not a retail store, so make sure the item is right for you, before bidding. Thanks for viewing and check out our other auctions @No reserve !!!
