Nte163a Bipolar Transistor - 10 Pieces

US $22.00

Great Neck, New York, United States
Jan 29th

Open on mobile:
QR code

Qty 10 New Original NTE Transistor NTE163A BIPOLAR TRANSISTOR, NPN, 700V, TO-3; Transistor Polarity:NPN; Collector Emitter Horizontal Deflection Description: The NTE163A is an NPN silicon transistor in a TO3 type case designed for use in large screen color deflection circuits. Features: Collector–Emitter Voltage: VCEX = 1500V Collector–Emitter Sustaining Voltage: VCEO(sus) = 700V Switching Times With Inductive Loads: tf = 0.4?s (Typ) @ IC = 4.5A Absolute Maximum Ratings: Collector–Emitter Voltage, VCEO(sus) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 700V Collector–Emitter Voltage, VCEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1500V Emitter–Base Voltage, VEB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5V Collector Current, IC Continuous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5A Peak (Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7.5A Peak Base Current, IB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4A Total Device Dissipation (TC = +95°C), PD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12.5W Derate Above 95°C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.625W/°C Operating Junction Temperature Range, TJ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . –65° to +115°C Storage Temperature Range, Tstg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . –65° to +115°C Thermal Resistance, Junction–to–Case, RthJC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6°C/W Maximum Lead Temperature (For Soldering, 1/8” from case for 5sec), TL . . . . . . . . . . . . . . . +275°C Note 1. Pulse Test: Pulse Width = 5ms, Duty Cycle

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	NTE
MPN	NTE163A
Model	NTE163A
Description	BIPOLAR TRANSISTOR, NPN, 700V, TO-3; Transistor
