Nuclear Pioneer Mca Multichannel Analyzer Gamma Spectrometer Module

US $850.00

Jerusalem, Israel
Jul 23rd

Open on mobile:
QR code

Unique Sell - MCA ver.4 Nuclear Pioneer Gamma Spectrometer Electronic Module (assembled unit, scintillation probe not included) for DIY Gamma Spectroscopy project Nuclear Pioneer MCA Multichannel Analyzer Electronic Module assembled into enclosure. Include internally installed rechargable 2000mAh LiPo battery, CR2032 battery, Tiny Geiger counter and microSD. The MCA can work as a robust Gamma Spectrometer and as a Scintillation Counter Survey Meter. It has high count rate performance for spectrum mode and for scintillation search mode. The board has regulated high voltage circuit with adjustable output of 600V-1000V postive polarity that allows to connect a NaI(Tl) probe with BNC cable. Probes with high impedance divider of ~50Meg-120Meg are supported. The pulse pre-amplifier set for an optimal gain, however you can re-adjust it if required. The MCA can detect Gaussian shape peaks in real-time. It has small library of radionuclides for hobby Gamma Spectroscopy. The counter calculate energy compensated doserate or can subtract previously saved background data file from the spectrum in real-time during spectrum acquisition. To use the MCA you need to add NaI(Tl) scintillation probe and BNC cable, Calibration of the hardware and the software is required to set a correct gain for your NaI(Tl) probe. Nuclear Pioneer MCA can work with small and big volume NaI(Tl) crystals probes. You may need to re-adjust high voltage with small screwdriver after connecting the probe to set the total gain of the analog circuit. Pulse pre-amplifier circuit is set for optimal pulse shape and gain, however in some circumstance you may need to re-adjust the pre-amplifier gain ratio (manual is included). Channel-to-Energy scale polynomial calibration can be done with selecting a scheme from the menu and simple picking 3-points on spectrum. Automatic calibration of CPS standard deviation for scintillation mode can be triggered from the menu. Other software settings are changed through serial port commands in UART-USB terminal or BLE terminal from the smartphone. The MCA has full speed 12MBit/sec USB port for calibration or spectrum data download. Any further firmware updates can be done with friendly Arduino Teensy bootloader by connecting USB cable and selecting ready hex file to upload. The module include internally installed tiny SBM-21 type sensor. The GM sensor CPS readings can be used in scintillation mode during prospecting in high radiation areas. MCA ver.4 specifications: ARM Cortex-M4 microprocessor 12-bit 4096 channels ADC TFT LCD 3.5” 480x320 with adjustable backlight level Rotary Encoder for controls 600V-1000V adjustable high voltage for photomultiplier probe positive polarity (NaI(Tl) probe is not included) included internal 400V Geiger Counter Adjustable gain & pulse shape pre-amplifier for an external photomultiplier probe Gamma Spectrometer Mode (tested up to 10.000 CPS) Scintillation Counter Mode with PMT and GM Sensor Easy Channel to Energy calibration with selectable scheme and channels pick Real time background subtract mode for gamma spectrometer Real time gaussian peak detection Linear or Logarithmic spectrum viewer Energy compensated dose rate 0.30 uSv/h doserate alert and 2-sigma CPS alert in scint.mode CPS standard deviation calibration for scint.mode Mute / Alert / Clicking in scint.mode Spectrum LCD zoom 512-4096 channels include internal Micro SD card for data storage RTC (include intenal CR2032 battery for date and time keeping) Internal temperature sensor include Bluetooth BLE module 12Mbit USB port for programming, calibration or data transfer Easy firmware update via USB and friendly bootloader Power supply: include 2Ah 3.7V LiPo battery 3.7V LiPo battery USB charger, software low battery alert UPC number: 634154871201 SKU: RH-MCA-4 The performance of the gamma spectrometer is strictly depending on your NaI(Tl) scintillation probe specifications and hardware/software calibration of the unit. Please avoid shorting high voltage on BNC socket and do not use hot plug of the probe because HV arcing across the BNC jack can ruin sensitive electronics. Recommended BNC cable part number CT2942-100. Recommended BNC jack for probe is 31-221-RFX. Menu description: RETURN – return from menu to current working mode display RESTART – restart a new spectrum SAVE SPECTRUM – will safe CSV file to uSD card with name XXXXXXXX.CSV, For example, 19051207.CSV file from 19 May 12:07 local time VIEW SPECTRUM – load CSV file from uSD card LCD ZOOM X – change LCD spectrum zoom 512-4096 channels LCD SCALE Y – toggle between linear and linear+log scale BACKGROUND – set or turn on/off background subtract mode UNLOCK CALIBRATION – allows to unlock 3-points channel-to-energy calibration and to select calibration scheme SPECTRUM TIME – set time in seconds for spectrum acquisition BACKLIGHT – change LCD backlight level BLE icon (on/off) – power on/off internal Bluetooth module SIGMA icon (on/off) – activate CPS standard deviation calibration for scintillation mode MCA icon – toggle gamma spectrometer mode SCI icon – toggle scintillation counter mode GM Tube icon – toggle internal Geiger Counter circuit (active in SCI mode only) You can download the user manual PDF and the latest firmware updates from manufacturer website. Lifetime support from the developer! Any further firmware updates for the device can be done with friendly bootloader application and USB cable. Not require a special programmer to upload the firmware. Package Include: 1pcs of Nuclear Pioneer MCA without probe Shipping with EMS / DHL / FedEx only, additional charges may be applied by your import customs.

“Developed and assembled in my Lab. Enclosure may have small cosmetic defects due to manual work and drilling. Has internally installed LiPO battery and SD card. Electronic module only, without probe and without BNC cable. The MCA must be calibrated by the buyer with their probe. Instruction manual can be downloaded.”

Country/Region of Manufacture

Israel

Require Calibration

YES

Radiation Detector Type

Scintillation Detector

MPN

RH-MCA-4

Scintillation probe

NOT INCLUDED

Brand

RHElectronics
