Occupancy Sensor, Pir, 2463 Sq Ft, White Cm 10, Extended Range 360 Degree Sensor

US $110.00

Norwich, Connecticut, United States
Jan 30th

Open on mobile:
QR code

OPTIONS LOW VOLTAGE RELAY (R) • Enables sensors to interface with other systems (e.g., BMS, lighting panels) • Provides dry contact closure via a SPDT, 1 Amp, 40 Volt relay • Only one relay needed per zone • Changes state when all connected sensors register unoccupied • Relay requires sensor power to function OCCUPANCY CONTROLLED DIMMING (D) • Provides dimming output to control 0-10 VDC dimmable ballasts • Provides a second occupancy timeout period that enables the lights to go to a dim setting before turning off • Adjustable max/min dim setting • Only one sensor per zone needs to have dimming output PHOTOCELL (P) • Auto set-point calibration • Two selectable modes of operation • On/Off mode: Photocell has full control during periods of occupancy • Inhibit mode: Photocell can prevent lights from turning on if adequate daylight is available, but cannot turn lights off PHOTOCELL W/ DIMMING (ADC) • Photocell within sensor maintains total room light level by controlling levels of 0-10 VDC dimmable ballasts • Photocell also has full on/off control during periods of occupancy • Provides a second occupancy timeout period that enables the lights to go to a dim setting before turning off Note: LampMaximizer+ features not available with ADC option LOW TEMP/HIGH HUMIDITY (LT) • Sensor electronics are coated for corrosion resistance • Operates down to -40? F/C) • Required for cooler/freezer applications OVERVIEW The CM 10 Series Extended Range 360? occupancy sensor incorporates Passive Infrared (PIR) technology into an attractive and economical sensor to provide maximum viewing from the ceiling. When mounted at 9 ft (2.74 m), this sensor views up to 28 ft (8.53 m) in all directions. Its circular coverage pattern is designed for walking motions; making it ideal for T-shaped intersections in corridors, or other areas where wall mounting a sensor is not practical. A long hallway, for example, may require a HW13 Series Hallway sensor at each end, with CM 10’s mounted in the center to fill in the distance. Low ceiling heights are also best covered by the CM 10. For example, when mounted at only 7 ft (2.13 m), the height of pick aisles in many distribution centers, the CM 10 provides a 32 ft (9.75 m) diameter pattern of coverage. In applications where detection of minor motion is also required, use the CM PDT 10 Series Dual Technology sensor. SENSOR OPERATION The sensor detects changes in the infrared energy given off by occupants as they move within the field-of-view. When occupancy is detected, a DC output goes high and can drive up to 200 mA of connected load. The sensor is powered with 12-24 VAC/VDC and typically operates with a PP20 or MP20 power pack, enabling complete 20 Amp circuits to be controlled. This innovative sensor requires no field calibration or sensitivity adjustments. LAMPMAXIMIZER® This sensor also contains patented LampMaximizer technology that allows users to aggressively target energy savings while still protecting lamp life. A minimum on timer, factory set at 15 minutes, helps preserve lamp life by eliminating all lamp cycles shorter than lamp manufacturers’ recommendations. A standard occupancy time delay is also present that ensures lights turn off (assuming minimum on timer has elapsed) if no occupancy is detected. This timer is factory set at 10 minutes to promote energy savings, but is adjustable between 30 seconds and 20 minutes. These adjustments can be done manually, through the units push-button, or automatically every two weeks through an advanced mode, called LampMaximizer+, that determines the optimum time delay in order to maximize both lamp life and energy savings. Additionally, this sensor maintains statistics on total lamp on time and number of cycles. EXTENDED RANGE 360? SENSOR CEILING MOUNT • LOW VOLTAGE • PASSIVE INFRARED (PIR) CM 10 FEATURES 100% Digital PIR Detection, Excellent RF Immunity 360? Coverage Pattern Push-Button Programmable Adjustable Time Delays No Field Calibration or Sensitivity Adjustments Required Convenient Test Mode 100 hr Lamp Burn-in Timer Green LED Indicator LAMPMAXIMIZER® TECHNOLOGY • Protects Lamp Life while Maximizing Energy Savings • Minimum On Timer (15 min default) • Occ. Time Delay (10 min defatult) • LampMaximizer+ Mode - Optimizes Lamp Life & Energy Savings (disabled by default) • Switch Counter (in 1000’s) • Total Lamp On Time (in khrs) PHYSICAL SPECS SIZE 4.55” Dia. (11.56 cm) 1.55” Deep (3.94 cm) WEIGHT 6 oz MOUNTING Ceiling Tile Surface 3.5” Octagon Box Single Gang Handy Box COLOR White ELECTRICAL SPECS OPERATING VOLTAGE 12-24 VAC/VDC CURRENT DRAW Standard, 4 mA w/ R option, 16 mA DIMMING LOAD Sinks < 20mA; ~40 Ballasts @ .5mA each RECOMMENDED POWER PACK PP20 E
