Okuma & Howa 2sp35hg Twin Spindle Cnc Lathe With Gantry 2001

US $7000

Comer, Georgia, United States
Jun 22nd

Open on mobile:
QR code

We are selling this Okuma & Howa 2SP due to a change in our business. The machine is in great shape. We have owned this machine since it was new. Have maintained the machine on a regular basis and have all maintenance records. The machine has several special software options including tool breakage detection which is a really productive feature to ensure when tools are worn or broken, the machine will stop, or switch to a redundant tool. 2001 OKUMA HOWA 2SP-35HG CNC TWIN SPINDLE TURNING CENTER, WITH GANTRY LOADER AND 16 PALLET STOCKER SIDE INPUT FEEDER TABLE. AND ALL INSTALLED WORKHOLDING AND OPTIONS INCLUDED IN SPECIAL PRICING. SPECIFICATIONS BASE MACHINE CAPACITY: MAXIMUM CUTTING DIAMETER.................... 14.96" MAXIMUM CUTTING LENGTH.........................9.06" DISTACE BETWEEN SPINDLES......................17.72" SPINDLE CENTER HEIGHT FROM FLOOR.........47.44" SPINDLES: SPINDLE MOTORS (FANUC Allpha X 2...........30 HP SPINDLE SPEED RANGE....................45- 3,500 RPM STANDARD CHUCK DIAMETER.......10" 3-Jaw Chucks SPINDLE NOSE............................................A2-8 TURRETS: TURRET TYPE (FANUC ALPHA 6/2000 MOTOR) V12 + V12 CURVIC COUPLING DIAMETER.....................6.61" CLAMPING FORCE...............................6,173 LBS INDEXING TIME(STATION TO STATION)....0.3 SEC. STANDARD TOOL SIZE.........................1.0" X 1.0" MAXIMUM BORING BAR SIZE..................1.75" OD MACHINE SIZE & MASS: FLOOR SPACE REQ...................215" X 152" x 160" WEIGHT...........................................24,200 LBS CNC LOADER INFORMATION GANTRY MODEL 3-AXIS SINGLE ARM CNC GANTRY LOADER WITH TURN OVER STATION , (16) STATION RIGHT SIDE ROTARY STACKER UNIT, 3 JAW LOADER CHUCKS, OVERHEAD GANTRY LOADER SPEEDS / TIMES: LONGITUDINAL (LEFT/RIGHT) A AXIS..........4724 IPM A AXIS STROKE.........................................77.17" VERTICAL B-AXIS......................................3937 IPM B-AXIS STROKE.........................................33.46" HORIZONTAL (IN/OUT) C AXIS....................1575 IPM C AXIS STROKE.........................................11.02" LOADING TIME..........................................12 SECONDS MINIMUM CYCLE TIME...............................45 SECONDS LOADER AND TURNOVER CHUCKS: JAW STROKE.........................................1.57" ACTUATION METHOD...................FORCED AIR Workpiece Stocker Specifications Max. Diameter:.................................... 11.1" Max Load on Pallet ...............................70 Kg. Max Height:......................................... 19.7" Number of Pallets:.......................... 16 Pallets EQUIPPED WITH THE FOLLOWING (1) GANTRY LOADER WITH (16) STATION PALLET POOL, FANUC 18T-B CNC CONTROL HEAVY - DUTY REAR DISCHARGE CHIP CONVEYOR, COOLANT TANKS, ALL BOOKS AND MANUALS The Machine is in plant under power in operation ready to inspect. Okuma's New List Price with Options $400,000.+ Any questions call Phil at 706-783-5091
