Olds, 1/2 Scale Model, Hit-miss / Stationary Engine Blueprint Set

US $19.95

  • Rockford, Illinois, United States
  • Jun 9th
Open on mobile:
QR code
For auction is a complete set of 6 blueprints that will allow the experienced hobbyist to build a 1/2 scale, gasoline-powered model of an Olds hit & miss, stationary engine, a design originally created by Breisch-Peters. The finished engine has 8.0" diameter flywheels with a 1-7/8" bore, 2.0" stroke piston.   Print details are listed below.    PRINT SIZE    PRINT NO.    CONTENTS  17" x 22"            E-31           engine body, bearing caps, main bearings  17" x 22"            E 3-2          piston, piston rings, wrist pin, crankshaft, flywheels, connecting rod & bearing cap 17' X 22"            E 3-3          cylinder head, rocker arm & rocker arm pin, push rod & guides, intake & exhaust valves, valve springs, valve                                                      spring retainers 17" x 22"            E 3-4          cam, governor cut-out arm, timing gears & parts, governor weights & controls 17" x 22"            E 3-5          mixing valve (carburetor), ignition system diagrams 17" x 22"            E 3-6          alternate magneto ignition system parts and assembly Please note: this auction is for one set of 6 blueprints ONLY. It does not include the completed engine versions (shown for illustration purposes only). _________________________ Shipping is $3.95. All prints will be packaged in a sturdy mailing tube and sent by USPS First Class Mail (with tracking) to any US address.
Condition:
New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...
Brand OLDS
Model OLDS Hit Miss
