Omega Ftb-102 Turbine Flow Meter 1/2" Flsc-35b Signal Conditioner

US $750.00

Campbellsville, Kentucky, United States
Jun 9th

Open on mobile:
QR code

OMEGA FTB-102 TURBINE FLOW METER 1/2" FLSC-35B Signal Conditioner Used piece. Comes as pictured. We have no further means to test the part in our shop. Description The FTB-100 Series of turbine meters have a sealed ball bearing design for high accuracy performance (± 1/2 % of reading,not full scale) at an economical cost. The non-metallic bearing retainers minimize friction, thereby allowing these meters to be used with clean fluids that have poor lubricating properties ( i.e.water). Ball bearings also give the widest linear flow range, particularly in larger turbines. Bearing replacement and clean-up are fast and easy, since all internal parts are easily accessible by removing a single nut. These turbine flowmeters have a low mass rotor design which allows rapid dynamic response, so they can be used in pulsating flow applications. Deflector cones eliminate downstream thrust on the rotor and allow hydrodynamic positioning of the rotor between the cones. This provides wider rangeability and longer bearing life than conventional turbine flowmeters. Integral flow-straightening tubes minimize the effects of upstream turbulence. FTB-100 Turbine Meters are available with integral signal conditioners (as shown in photo) which provide scaled and unscaled frequencies, 4-20 mA, or 0-5 Volt outputs. Units without integral signal conditioners are supplied with mating connector for two-wire hook-up. SPECIFICATIONS Accuracy: ± 1/2 % of reading Repeatability: ±0.1% of reading Maximum Temperature Range: -268 to 232°C (-450 to 450°F) Maximum Intermittent Overrange: 150% of maximum range Minimum Output Amplitude: 30 mV Peak-to-Peak Unscaled Pulse Materials of Construction: Body: 304 stainless steel; 1/2 NPT bodies contain Silver Solder. 3/4 NPT and larger are welded. Rotor: 17-4 pH steel Bearings: Ceramic Minimum straight pipe requirements: 10 pipe diameters upstream, 5 downstream Model No. Fittings Linear Flow Range Water Max Operating Pressure Max Pressure Drop Length mm (in) Nominal K-Factor Pulses/Gal Weight kg (lb) LPM GPM FTB-101 1/2 MNPT 1.32 to 13.2 0.35 to 3.5 5000 psig 3.0 psid 62 (2.45) 13,000 0.4 (1) FTB-102 1/2 MNPT 2.84 to 28.4 0.75 to 7.5 5000 psig 5.0 psid 62 (2.45) 10,000 0.4 (1)

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Omega
MPN	FTB-102
Model	FTB-102
