Omni Vision Lp0615e3y Display Module For Spectrum Analyzer T46699

US $225.00

  • Silverton, Oregon, United States
  • Jun 9th
Open on mobile:
QR code
Quantity Sells:  1 Manufacturer:  Omni Vision Description:  6” Monochrome CRT This Omni Vision replacement 6" monitor is offered in an open frame chassis as a direct drop-in for the Matsushita 6" monitor. This monitor requires analog video or separate TTL horizontal and vertical sync. The replacement 6” CRT provides great viewing of high brightness, sharply focused displayed data. The main circuit board is made of industrial grade epoxy/fiber glass reinforced material with an FR4 rating General Information:  On board service controls Brightness, Contrast, Focus, Horizontal (Size, Centering, Hold), Vertical (Size, Centering, and Linearity)  Input signal type standard - Analog Video - 0 to 0.7 volts Horizontal & Vertical Sync Signals - TTL level 0 to 5 volts  Input Power - Standard +12 vdc @ 1.5 A (typical)  Signal & Power Input Connector - Standard card edge connection or special interface headers  Temperature - Operating from 0 to +55 degrees C Storage from -20 to +65 degrees C Features -  All circuitry is on a single, double sided, plated through PCB.  All controls are easily accessible from the top of monitor.  The video display is stabilized through the use of a voltage controlled, temperature compensated feedback to synchronized free run oscillator.  Electronic horizontal video centering.  Geometric distortion - within 2 % EIS Standard Dot/Ball Chart or variation between adjacent characters not more than 10 % in alpha numeric display applications  High Voltage - Over 8 kV at 50 microamperes of beam current with no more than 0.5 kV variation from zero beam to 100 microamperes beam current.  Datasheet: www *dot* omnivisionusa *dot* com/monitors/replacement-crt/crt-monitors/industrial-crt-monitors-pdf/SL-Replacement-Mono-6-in-CRT-n-drwg-0512 *dot* pdf EbayA-208
“New Surplus - no manufacturer warranty.”
Brand Omni Vision
MPN LP0615E3Y
Model 2090-0539
Country/Region of Manufacture Unknown
