Omron H3cr-a-300 Ac100-240 Dc100-125 Timer Eu Seller!!!

US $69.99

Vilnius, Lithuania
Jan 29th

Open on mobile:
QR code

OMRON H3CR-A-300 AC100-240 DC100-125 Timer Ratings Rated supply voltage 100 to 240 VAC, 50/60 Hz 100 to 125 VDC, ripple: 20% max. Operating voltage range 85% to 110% of rated supply voltage Input signals Reset, Start, Gate Input method No-voltage input No-voltage input ON impedance: 1 kOhm max. ON residual voltage: 1 V max. OFF impedance: 100 kOhm min. Minimum input signal width 0.05 s Power consumption (Relay ON) Approx. 2 VA, 1.6 W (at 240 VAC, 60 Hz) Power consumption (Relay OFF) Approx. 1.3 VA, 1.1 W (at 240 VAC, 60 Hz) Reset voltage 10% max. of rated supply voltage Number of time ranges 14 Time ranges 0.05 s to 1.2 s, 0.12 min to 1.2 min, 0.12 h to 1.2 h, 1.2 h to 12 h, 0.3 s to 3 s, 0.3 min to 3 min, 0.3 h to 3 h, 3 h to 30 h, 1.2 s to 12 s, 1.2 min to 12 min, 12 h to 120 h, 3 s to 30 s, 3 min to 30 min, 30 h to 300 h Operating mode Signal ON/OFF delay, One shot output Control output Type Relay output (DPDT) Control output (Contact output) Switching capacities (resistive load (cos (phi) = 1)): 250 VAC 5 A, 30 VDC 5 A Minimum applicable load: 10 mA at 5 VDC (failure level: P) Ambient temperature Operating: -10 to 55 CEL Storage: -25 to 65 CEL (with no icing) Ambient humidity Operating: 35 to 85% RH Storage: 35 to 85% RH Characteristics Accuracy of operating time +/- 0.2% max. (FS) (+/- 0.2% +/- 10 ms max. in a range of 1.2 s and 3 s) Setting error -5 to 5% (FS) Reset time 0.1 s max. Influence of voltage +/- 0.2% FS max. (+/- 0.2% +/- 10 ms max. in a range of 1.2 s and 3 s) Influence of temperature +/- 1% FS max. (+/- 1% +/- 10 ms max. in a range of 1.2 s and 3 s) Insulation resistance 100 MOhm min. (at 500 VDC) Dielectric strength between current carrying metal parts and exposed non-current carrying metal parts: 2000 VAC, 50/60 Hz for 1 min between control output terminals and operating circuit: 2000 VAC, 50/60 Hz for 1 min between contacts of different poles: 2000 VAC, 50/60 Hz for 1 min between non-continuous contacts: 1000 VAC, 50/60 Hz for 1 min Impulse withstand voltage between power terminals: 3 kV between exposed non-current-carrying metal parts: 4.5 kV max. Noise immunity +/- 1.5 kV (between power terminals) and +/- 600 V (between input terminals), square-wave noise by noise simulator (pulse width: 100 ns/1 us, 1-ns rise) Static immunity Mulfunction: 8 kV Destruction: 15 kV Vibration resistance (Destruction) 10 to 55 Hz, 0.75 mm single amplitude each in X, Y, and Z directions for 2 hours Vibration resistance (Malfunction) 10 to 55 Hz, 0.5 mm single amplitude each in X, Y, and Z directions for 10 min Shock resistance (Destruction) 1000 m/s**2, 3 times each 6 directions Shock resistance (Malfunction) 100 m/s**2, 3 times each 6 directions Mechanical Life expectancy (relay output) 20000000 operations min. (under no load at 1800 operations/h) Electrical Life expectancy (relay output) 100000 operations min. (5 A at 250 VAC, resistive load at 1800 operations/h) Degree of protection IEC60529 (JEM): IP40(panel surface) Applicable standard (UL) Standard No.: UL508 File number: E41515 Applicable standard (CSA) Standard No.: CSA C22.2 No.14 File number: LR22310 Applicable standard (LR) 99/10010 Applicable standard (NK) A-323-1B Applicable standard (CCC) Printed Applicable standard (EC Directive (Machinery Directive) ) EN61812-1 Applicable standard (EC Directive (Low Voltage Directive) ) EN61812-1 IEC60664-1 4 kV/2 Applicable standard (EC Directive (EMC Directive) ) EMI: EN61812-1 Emission Enclosure: EN55011 Group1 class A Emission AC mains: EN55011 Group1 class A EMS: EN61812-1 Immunity ESD: IEC61000-4-2(6 kV contact discharge, 8 kV air discharge) cRF-interference: IEC61000-4-3(10 V/m, AM radio waves (80 MHz to 1 GHz), 10 V/m, Pulse-modulated waves (900 MHz +/- 5 MHz)) Immunity Conducted Disturbance: IEC61000-4-6(10 V (0.15 to 80 MHz)) Immunity Burst: IEC61000-4-4(2 kV power-line, 2 kV I/O signal-line) Immunity Surge: IEC61000-4-5(1 kV line to line, 2 kV line to ground) External connection method 11-pin round socket Case color Munsell 5Y7/1 (Light gray) Weight Approx. 90 g
