Omron Limit Switch Shl-q2255

US $79.95

FARIDABAD, HARYANA, India
Jul 20th

Open on mobile:
QR code

Limit Switch Pack of 1 Pcs Shape/Structure Enclosed Limit switches ctuator Panel mount roller plunger 11 dia. x 4.7 Stainless sintered alloy roller Frequency 50/60 Hz Contact form SPDT Load General load Ratings (AC): Non-Inductive load Resistive load: 10 A at 125 VAC/10 A at 250 VAC/2 A at 480 VAC Lamp load: 1.5 A at 125 VAC/1.5 A at 250 VAC Inductive load: 3 A at 125 VAC/2 A at 250 VAC Motor load: 2.5 A at 125 VAC/1.5 A at 250 VAC Ratings (DC): Non-Inductive load Resistive load: 10 A at 8 VDC/10 A at 14 VDC/5 A at 30 VDC/0.4 A at 125 VDC/0.2 A at 250 VDC Lamp load: 2 A at 8 VDC/2 A at 14 VDC/1.5 A at 30 VDC/0.4 A at 125 VDC/0.2 A at 250 VDC Inductive load: 5 A at 8 VDC/5 A at 14 VDC/1.5 A at 30 VDC/0.05 A at 125 VDC/0.03 A at 250 VDC Motor load: 2 A at 8 VDC/2 A at 14 VDC/1.5 A at 30 VDC/0.05 A at 125 VDC/0.03 A at 250 VDC Inrush current NC: 15 A max. NO: 15 A max. Ambient temperature Operating: -10 to 80 (with no icing) Ambient humidity 35 to 95% RH Permissible operating frequency Electrical: 30 operations / 1 minute max. Mechanical: 120 operations / 1 minute max. Contact resistance (Initial value) 15 m max. (initial value for the built-in switch whentested alone) Insulation resistance 100 M min. (at 500 VDC) Dielectric strength Between each terminal of the same polarities: 1,000 VAC 50/60 Hz 1 min Between each terminal and non-live-metallic part: 2,000 VAC 50/60 Hz 1 min Impulse withstand voltage Between each terminal and non-live-metallic part: 2.5 kV Durability Electrical: 500,000 operations min. Mechanical: 10 million operations min. Vibration resistance Malfunction: 10 to 55 Hz, 1.5 mm double amplitude Shock resistance Destruction: 1,000 m/s2 max. Malfunction: 300 m/s2 max. Pollution degree 3 (EN60947-5-1) Degree of protection IP67 Classification of protection against electric shock Class II (Grounding not required with double) insulation Operating Force (OF) Standard value 9.81 N max. Release Force (RF) Standard value 1.96 N min. Pre-Travel (PT) Standard value 1.5 mm max. Movement Differential (MD) Standard value 0.5 mm max. Over-Travel (OT) Standard value 2 mm min. Operating Position (OP) Standard value 43±0.8 mm

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Number in Pack	1
Finish	Brass
Features	Illuminated
Number of Circuits	1
Number of Outlets	1
Operation Method	On/Off
Maximum Amperage	40 A
Brand	Omron
Suitable For	Wall
Color	Gray
Country/Region of Manufacture	Japan
Mounting Style	Panel
Material	ABS/Plastic
Termination Type	Screw
Number of Positions	1
Number of Phases	1
Model	SHL-Q2255
Type	Connector
Current Type	AC/DC
