Omron Proximity Switch 12 To 24 Vdc Tl-w3mc1

US $62.72

Carol Stream, Illinois, United States
Mar 9th

Open on mobile:
QR code

Untitled Document Omron Proximity Switch TL-W3MC1 Inductive Sensing: A Sensing technology that identifies the presence of metallic objects by detecting eddy current losses in a magnetic field produced at a sensing face. Features: Detects Metal Targets, Ideal for Applications Which Require High Precision Detection= High Quality ABS Plastic Housing for Durability LED Operation Indicator Allows Quick Confirmation of Output Status DC 3-Wire, Pre-Wired with 2 Meter PVC Cable for Durability Small Size Allows Mounting in Tight Spaces Specifications: Supply Voltage Range: 10-30 VDC Load Rating: 100 mA (DC) Enclosure Ratings Include IEC IP67, NEMA 1, 3, 4X, 6, 12 and 13 Approvals: CE Mark Type Unshielded Sensing method Inductive type Sensing distance 3 mm -10% to +10% Setting distance 0 to 2.4 mm Differential distance 10% Max. of sensing distance Sensing object Ferrous metal (Sensitivity lowers with non-ferrous metals.) Standard sensing object Iron 12*12*1mm Response frequency 600 Hz (average) Power supply voltage 12 to 24 VDC (ripple(p-p) :10% Max.) Operating voltage range 10 to 30 VDC Current consumption 15 mA Max. (at 24VDC) Control output (Output type) NPN open collector output Control output (Switching capacity) 0 to 100 mA (30VDC Max.) Control output (Residual voltage) 1 V Max. (under load current with cable length of 2m) Indicator Detection indicator(red) Operation mode NO Protective circuit Surge suppressor Power supply reverse polarity protection Standard or Different frequency Standard Ambient temperature Operating: -25 to 70 CEL Storage: -25 to 70 CEL (with no icing or condensation) Ambient humidity Operating: 35 to 95 %RH Storage: 35 to 95 %RH (with no condensation) Temperature influence +-10% Max. of sensing distance in temperature range of -25 to +70CEL (As the basis for sensing distance of 23CEL) Voltage influence +-2.5% Max. of sensing distance in rated voltage range +-10%. (As the basis for sensing distance at standard power voltage) Insulation resistance 50 M OHM Min. at 500VDC between charged parts and the case Dielectric strength 1000 VAC 50/60 Hz for 1 minute between charged parts and the case Vibration resistance 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions Shock resistance 500m/s2 for 3 times each in X, Y, and Z directions Degree of protection IEC60529: IP67 Company standard: Oil-proof Applicable standard (EC Directive (Low Voltage Directive)) EN60947-1 EN60947-5-2 Applicable standard (EC Directive (EMC Directive)) EMI: EN60947-5-2 Emission Enclosure: CISPR11 Group 1 class A EMS: EN60947-5-2 Immunity ESD: IEC61000-4-2 Immunity RF-interference: IEC61000-4-3 Immunity Conducted Disturbance: IEC61000-4-6 Immunity Burst: IEC61000-4-4 CE marking: Equipped Applicable standard (CCC mark) Not equipped Connection method Pre-wired models (Cable length: 5 m) Material (case) Heat-resistant ABS resin Material (sensing surface) Heat-resistant ABS resin Accessories Instruction manual, Mounting bracket techparts99

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	OMRON
MPN	TL-W3MC1
