Omron Rotary Encoder E6b2-cwz6c E6b2cwz6c 1000p/r New In Box Free Ship #j16 Lx

US $27.98

shenzhen, guangdong, China
Jan 29th

Open on mobile:
QR code

*Condition: NEW *Package included: 1 pcs OMRON Rotary Encoder E6B2-CWZ6C 1000P/R (Black Label) Specifications: Encoding method Incremental Power supply voltage 5 VDC -5% to 24 VDC +15% (ripple (p-p): 5% Max.) Current consumption 80mA DC Max. Inrush current Current: approx. 9 A (Time: approx. 0.3 ms) Resolution (Single turn type) 1000 P/R Output phases A, B and Z Control output (Output type) NPN open collector output Control output (Load current) 35 mA Max. (sink current) Control output (Residual voltage) (DC) 0.4 V Max. (load current:at 35mA Max.) Starting positional point Equipped Load power supply voltage 30 VDC Max. Max. response frequency 100 kHz Phase difference on output 90 DEG -45 to +45 DEG Rise and fall times of output Rise time of output: 1 us Max. Fall time of output: 1 us Max. (Output voltage: 5V, load resistance: 1k OHM, cable length: 2m Max.) Starting torque Room temperature: 0.98 mN.m Max. Moment of inertia 1*10-6kg.m2 Max. Shaft loading Radial: 30 N Thrust: 20 N Max. permissible rotation 6000 r/min Mechanical life expectancy 100 million rotations Min. Protective circuit Output short-cut protection Power supply reverce polarity protection Ambient temperature Operating: -10 to 70 CEL Storage: -25 to 85 CEL (with no icing or condensation) Ambient humidity Operating: 35 to 85 %RH Storage: 35 to 85 %RH (with no condensation) Insulation resistance 20 M OHM Min. at 500 VDC between charged parts and the case Dielectric strength 500 VAC at 50/60 Hz for 1 minute between charged parts and the case Vibration resistance 10 to 500 Hz, 2-mm or 150m/s2 double amplitude for 11 min 3 times each in X, Y, and Z directions Shock resistance 1000m/s2 for 3 times each in X, Y, and Z directions Degree of protection IEC60529: IP50 Applicable standard (EC Directive (EMC Directive)) EMI: EN50081-2 Emission Enclosure: EN55011 Group 1 classA Emission AC mains: EN55011 Group 1 classA Immunity ESD: IEC61000-4-2 Immunity RF-interference: IEC61000-4-3 Immunity Burst: IEC61000-4-4 CE marking: Equipped Connection method Pre-wired models (Cable length: 2 m) Material (case) ABS Material (body) Aluminum Material (shaft) SUS420J2 *Shipping address: We ship the item to your Paypal address. So please double check it. *Combine shipping: If you buy more than 1 item, we will give you 10% discount of total shipping fee. *Send out time: The item will be shipped out in 3 days after clear payment. *Delivery time: Depending on destination.Post strike,storm,volcano etc are not considered. Table of delivery time(typical countries) Typical Country Delivery Time Working Days 5-10 11-20 21-25 25-30 >30 Working Days + Saturday + Sunday 7-14 15-24 25-35 36-42 >42 United States Rate (item arrived) 60% 35% 5% x x United Kingdom Rate (item arrived) 31% 60% 9% x x Australia Rate (item arrived) 21% 68% 11% x x Germany Rate (item arrived) 15% 66% 19% x x Canada Rate (item arrived) 22% 71% 7% x x Singapo Rate (item arrived) 41% 53% 6% x x Russia Rate (item arrived) 0% 42% 53% 5% x Brazial Rate (item arrived) 0% 38% 49% 13% x *Paying method: We accept Paypal only. *Paying time:Payment must be made within 7 days after the auction end. *Defect of item:Please contact us in 7 days after receving it and we will refund or reship it as you like. But the customers must pay shipping fee. *Size change:You can change it, but you need pay shipping fee. *Dislike item:If you dislike the item after your receiving it, you can send it back and we can refund after our receiving it. But you need pay shipping fee.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	E6B2-CWZ6C
Country/Region of Manufacture	China
