On Semiconductor Adp3212mnr2g Qfn Ship From Us

US $1.99

Tucson, Arizona, United States
Jan 29th

Open on mobile:
QR code

Our mission is to give you the e–components you need without having to deal with long delivery times from China. All of our components are already in the US. You can order 1pcs of any part, there is no minimum for ordering. just place an order and you will have your parts in no time! All components come in brand new condition with a 2 months limited warranty, you have plenty of time replace them if needed. 7-Bit, Programmable, 3-Phase, Mobile CPU Synchronous Buck Controller The APD3212/NCP3218/NCP3218G is a highly efficient, multi–phase, synchronous buck switching regulator controller. With its integrated drivers, the APD3212/NCP3218/NCP3218G is optimized for converting the notebook battery voltage into the core supply voltage required by high performance Intel processors. An internal 7–bit DAC is used to read a VID code directly from the processor and to set the CPU core voltage to a value within the range of 0.3 V to 1.5 V. The APD3212/NCP3218/NCP3218G is programmable for 1–, 2–, or 3–phase operation. The output signals ensure interleaved 2– or 3–phase operation. The APD3212/NCP3218/NCP3218G uses a multimode architecture run at a programmable switching frequency and optimized for efficiency depending on the output current requirement. The APD3212/NCP3218/NCP3218G switches between single– and multi–phase operation to maximize efficiency with all load conditions. The chip includes a programmable load line slope function to adjust the output voltage as a function of the load current so that the core voltage is always optimally positioned for a load transient. The APD3212/ NCP3218/NCP3218G also provides accurate and reliable short–circuit protection, adjustable current limiting, and a delayed power–good output. The IC supports On–The–Fly (OTF) output voltage changes requested by the CPU. The APD3212/NCP3218/NCP3218G are specified over the extended commercial temperature range of –40°C to 100°C. The ADP3212 is available in a 48–lead QFN 7x7mm 0.5mm pitch package. The NCP3218/NCP3218G is available in a 48–lead QFN 6x6mm 0.4mm pitch package. ADP3212/NCP3218 has 1.1 V Vboot Voltage, while NCP3218G has 987.5 mV Vboot Voltage. Except for the packages and Vboot Voltages, the APD3212/NCP3218/ NCP3218G are identical. APD3212/NCP3218/NCP3218G are Halogen–Free, Pb–Free and RoHS compliant. Features • Single–Chip Solution • Fully Compatible with the Intel® IMVP–6.5 Specifications • Selectable 1–, 2–, or 3–Phase Operation with Up to 1 MHz per Phase Switching Frequency • Phase 1 and Phase 2 Integrated MOSFET Drivers • Input Voltage Range of 3.3 V to 22 V • Guaranteed ±8 mV Worst–Case Differentially Sensed Core Voltage Error Over Temperature • Automatic Power–Saving Mode Maximizes Efficiency with Light Load During Deeper Sleep Operation • Active Current Balancing Between Output Phases • Independent Current Limit and Load Line Setting Inputs for Additional Design Flexibility • Built–In Power–Good Blanking Supports Voltage Identification (VID) On–The–Fly (OTF) Transients • 7–Bit, Digitally Programmable DAC with 0.3 V to 1.5 V Output • Short–Circuit Protection with Programmable Latchoff Delay • Clock Enable Output Delays the CPU Clock Until the Core Voltage is Stable • Output Power or Current Monitor Options • 48–Lead QFN 7x7mm (ADP3212), 48–Lead QFN 6x6mm (NCP3218/NCP3218G) • Vboot = 1.1 V (ADP3212/NCP3218) Vboot = 987.5 mV (NCP3218G) • These are Pb–Free Devices • Fully RoHS Compliant Applications • Notebook Power Supplies for Next–Generation Intel Processors

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	ON Semiconductor
MPN	ADP3212MNR2G
Model	ADP3212MNR2G QFN
