Optical Comparator Profile Projector With Quadra-chek Ecad

US $16,995.00

Providence, Rhode Island, United States
Jul 8th

Open on mobile:

You are bidding on a Certified Comparator Products CC-14 Optical Comparator & Heidenhain Quadra-Chek with eCAD in excellent working condition! HARDWARE... 14” image diameter screen 8” x 4“ XY travel Quick release X axis and fine adjustment knobs in X and Y Heavy cast mineral composite base worktable support structure 0.00004” XY scales Optics & Illumination... Fully telecentric Internal quick change lens mount and lens storage rack 3.4” constant working clearance 10X mag lens, standard 2 vivid TruLight™ all-LED illuminators available DRO & Software... Heidonhain Quadra-Chek eCAD eCAD virtual chart projected onto the same part Certified Comparator Products (CCP) has introduced the eCAD virtual chart gage system, an electronic overlay package available on specially configured CCP optical comparators. eCAD creates a "virtual" chart gage, using DLP technology to accurately project a CAD model with tolerance bands onto the comparator screen. The CAD file is synchronized to the worktable motion so that as the table is moved, the projected CAD image tracks it accurately. As magnification is changed, eCAD automatically adjusts the CAD image magnification, so the CAD overlay is always correctly sized, the company said. eCAD is designed to reduce costs by eliminating the need to maintain a large inventory of certified chart gages, and can improve accuracy by eliminating the errors inherent in making the chart master from the CAD file, the company said. Chart storage, cleaning and changeover requirements are eliminated. eCAD is also designed to add flexibility to the comparator, enabling new part designs to be measured immediately without the need to make new charts. With eCAD, the comparator is a suitable measurement tool for rapid prototyping, said CCP. eCAD is designed to represent multiple tolerance zones, using color bands to indicate various levels of precision requirements and to project tolerance zones in user-defined ways as translucent overlays or silhouettes. Change mags with the available magnification lenses on the comparator, which are automatically supported by the eCAD software. Parcentrality and keystone error compensation is also supported. eCAD supports a range of common CAD file formats, including Gerber, Excellon, HPGL, PRT, EPS and DWG. Part origin and skew alignment are provided for, and both horizontal and vertical mirror image projection are supported, along with identification of material side, enabling maximum utilization and flexibility in the measurement setup, said the company. Screen Size 14” diameter screen, with integral hood Screen Type Ground glass with 90° centerlines and clips for mounting standard 14” overlay charts Protractor Digital screen display, ±360° readout with 1’ (0.017°) resolution Optical System Telecentric, horizontal, with inverted reversed image, 3.4” constant working clearance, Includes: 10X projection lens Lens Mount Internal, manual, quick-change lens storage rack with operator access Throat Clearance 8.5” XY Motion Manual, with quick release X axis and fine adjustment knobs in X and Y XY Travel Range 8” x 4”; focus travel - 1.5” with precision fine adjustment Optional Travel Extended X axis travel - 12” XY Positioning Precision, with heavy duty cast iron substage for vertical motion and focus control Worktable Precision machined aluminum with fixturing slot, 16” x 4.75”, 45 lb load capacity System Dimensions, (approx DWH) 35.9” x 30”(including DRO) x 33” Weight, approximate 375 lb Illumination (TruLight™) 1. Profile light, bright green LED, continuously variable intensity 2. Oblique (Dark Field), Ringlight with 8 white LEDS, 6 switch-selectable patterns for effective directional lighting; continuously variable intensity 115 VAC, 50/60 Hz, 1 0.00004” Palm Tree Catalog # ILR-000000-070121-C * All information deemed accurate but may vary from model to model. Contact Larry for any questions you may have... Contact Four Zero One - Nine Six Five - Five Five Five Seven __________________________________________ Equipment Financing Available, please contact us! Fast Application, it’s all filled in for you! Online leasing applications (get LOW monthly payments)… * Please Note: Not all machines may qualify for Leasing. Payments: We accept all Major Credit Cards, Bank Wires, Company and Personal Checks. SHIPPING: Contact us for great rates on shipping... We always get better rates... Please email us for a rigging and shipping quote; just include the zip code when inquiring and if you have a loading dock or if you are a residential delivery, Thanks! Contact: Larry at Four Zero One - Nine Six Five - Five Five Five Seven or message through ebay... We also ship worldwide. CONDITIONS: All quotations are for immediate acceptance. They are subject to withdrawal, change and prior sale without notice. Shipping dates are only approximate and contingent upon delays beyond our control. All orders received are binding only when they have been accepted and acknowledged by us in writing. Provisions in customer’s purchase orders contrary to these conditions shall not be binding upon us unless accepted in writing. Unless otherwise specified, prices quoted are F.O.B. shipping point, exclusive of State, County and Federal taxes which must be added where applicable. Insurance on shipment must be requested by email, there will be an additional charge for shipping insurance. Shipping destination must be available to receive the shipment… any costs incurred on delays due to the buyers’ destination being unable to receive the shipment and/or additional services required, will be the responsibility of the buyer. Care is taken to give reliable specifications, but these are not guaranteed. We reserve the right to correct typographical errors. All used equipment is sold "as is". INDEMNIFICATION: Used Machines may not incorporate approved activating mechanisms, operator safety devices or safety guards as required by OSHA or otherwise. It is the user's responsibility that the said machines be so equipped and safeguarded to meet OSHA and any other requirements before placing such machinery into operation. User agrees to indemnify and hold Seller harmless of and from any and all claims or liabilities from accidents involving these machines caused by failure of user, his employees, or agent to follow instructions, warnings, or recommendations furnished by manufacturer, or Seller, or by failure of user to comply with Federal, State and Local laws applicable to such equipment including the Occupational Safety and Health Act of 1970. User shall notify Seller promptly after occurrence of any accident involving these machines, and shall cooperate fully with Seller. or Seller's agent in investigating and determining the cause of said accident. Good Luck Bidding and check out our Ebay store weekly to see our new listings! Click here>>http://stores.ebay.com/Palm-Tree-Specialties

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Model	CC-14
Instrument Type	Optical Comparator
Modified Item	No
MPN	CC-14
Country/Region of Manufacture	United States
Brand	Certified Comparator Products
Custom Bundle	No
