Oriel Instaspec Iv Ccd Array Detector Head

US $200.00

Encino, California, United States
Mar 1st

Open on mobile:
QR code

InstaSpecIV CCD Sensor Head by Oriel Model 77131 This auction is for the head only. It is untested, but appears to be in excellent cosmetic condition. There are no cables or readout electronics. This head is based on a linear CCD sensor. The O-ring gasket forms a light-tight seal up against the mounting flange of the spectrograph. The CCD is isolated. The two hose connectors at the top for water cooling. The spectrograph/CCD ensemble is in fact an "imaging" system in that the vertical column height of the chip has 64 or 256 pixels (not sure) From Oriel Catalog: Spectroscopic systems Slow scan scientific grade imaging systems Air cooling to -55 °C High speed data acquisition, up to 1 MHz True 16-bit dynamic range InstaSpec™ IV is our family of imaging and large area spectroscopic CCD systems. Dark current is an impressive InstaSpec™ IV is our family of imaging and large area spectroscopic CCD systems. We offer sealed and evacuated detector heads which reach temperatures of -55 °C without water cooling! Dark current is an impressive The CCD chips in the detector heads are ~1 inch long to match the flat focal plane produced by most spectrographs. The readout register is along the long (dispersion) axis allowing use of the most efficient readout method, commonly referred to as Full Vertical Binning. This binning scheme eliminates the need for any shutter and offers sustained spectral acquisition rates up to 250 spectra per second with a 1024 pixel array, or as high as ~800 spectra per second with a 385 pixel array.

“Good cosmetic condition. Untested.”
