Original New Spectra Polars Pq-512/15aaa For Leopard/jhf/flora Smart Uv Printer

US $1000

Fengtai, Beijing, China
Jun 20th

Open on mobile:
QR code

Overview Spectra Polaris PQ-512/15 AAA printhead Model PRH-SPE-007 Number of addressable jets 512 Print width 64.897 mm (2.555 inches) Single color (4 rows of jets) 127 microns [0.005 in.] (200 dpi) Two color (2 rows of jets/per color) 254 microns [0.010 in.] (100 dpi) Jet straightness, 1 sigma* 2.0 mrad [0.11°] Nominal drop velocity 8 m/s Calibrated drop mass 15ng Compatible jetting fluids UV-curable, organic solvents, aqueous Adjustment for drop size 15 - 30 picoliters Drop Size 15 pl Maximum Frequency 40 kHz Drop Size 30 pl Maximum Frequency 25 kHz Operating temperature range up to 60° C Fluid viscosity at jetting 8 to 20 centipoise Dry weight 160 grams To be used with: LIYU PS3204-S512, LIYU PS3208-S512; Rodin P9320-B (4H), Rodin P9320-B (8H); Flora PP2512UV, SMART uv printer; JHF UV R5000, JHF UV R3300, JHF UV R5000S, JHF UV R3300S; LEOPARD E3000, LEOPARD S2600, Anhui Liyu Innova PS, Infiniti Fina 250Q / Fina 320Q, Eurotech Aslan / Leo / Lion, Gongzheng GZCK 3212 AK, Flora LJ 320P, Rodin P9320-B, Sun Neo UV-LED Flatbed, Teckwin TeckUV 3200SR / TeckStorm TS600 / TeckStorm TS300, CET Color X-Press X500 / X-Press X500h / X-Press X1000 / X-Press X1000hl, Truepress Jet W3200UV, Wit-Color Ultra 4000-3304 / Ultra 4000-3308 Remarks: original Description: • The Polaris PQ-512/15 AAA Printhead has 512 independent channels arranged in multiple rows at 200 dots-per-inch spacing for single color operation, or 100 dots-per-inch spacing for two color operation. • The printhead is designed for binary jetting using a 15-picoliter native drop size with 8-meters per second nominal drop velocity for jetting fluids in the 8 to 20 centipoise range. Using VersaDrop jetting technology, the printhead is capable of adjustable binary operation at drop sizes up to 30 picoliters with resolutions up to 1000 dpi. • Building upon the legendary reliability and performance of the Spectra Nova and Galaxy Printheads, the Polaris PQ-512 AAA family of printheads uses field proven materials and a repairable design to deliver a long service life and consistent output. And by leveraging the inherent flexibility of the Q-Class platform, the Polaris PQ-512 AAA offers even greater jetting performance, nozzle packing density, and configuration flexibility. • The PQ-512/15 AAA Printhead is compatible with a broad range of inks, including UV-curable, aggressive organic solvent and aqueous inks and associated maintenance fluids. • The unique design of Polaris PQ-512/15 AAA Printhead allows each 256-channel module to be replaced and accurately registered in the field with no special tools or recalibration. An integral mounting bezel with precision registration points enables drop-in alignment with other carriage features. • Two electrical connectors contain eight serial data lines that supports fire frequencies in excess of 50 kHz. • The flexible fluid interface allows single and two-color operation. Each 256-channel module is dual ported to facilitate easy priming, flushing and ink recirculation. Heaters and temperature sensors allow precise control of ink viscosity at jetting temperatures up to 60°C. Features: • 15 picoliter nominal drop size; • 512 individual addressable nozzles; • Incorporates VersaDrop™ binary jetting capability; • Excellent channel-to-channel uniformity; • High frequency continuous operation; • Designed for long service life; • Supports UV-curable, solvent, and aqueous-based inks; • Configurable for single- and two-color operation; • Integral mounting bezel with precision features; • Optimized for high viscosity jetting fluids; • Built-in heaters and temperature sensors; • Operation up to 60°C [140°F]; • Simplified field repair with no special tools required. Application: The Spectra Polaris PQ-512/15 AAA Printhead is a high performance inkjet printhead designed for a broad range of industrial and commercial printing applications at resolutions up to 1000 dpi. Robust construction and repairable design make it ideal for solvent, UV and aqueous based wide format printers built for demanding production environments. Attention: 1. The printhead is required to be installed by professional persons. 2. Due to the nature of printer parts and the many factors that go into installing them, we do not accept returns or give refunds on electronic or service parts. Once the package is delivered, it is the customer's responsibility to check the package for damage. If there is any visible damage on the package, please refuse the shipment and call us at +86(10) 63705868 ext 607 or send email to info AT sign-in-china.com 3. Please seriously pay attention on information of printhead model while purchasing from us. Once received your item, please inspect if the printhead matches up with the model you required.If you have any problems, it is very important that contact us as soon as possible before installing it onto machine. Please be aware that we don't accept any return and refund once the printhead is installed on the machine. 4. The fragile sticker pasted on printheads is a label to prove that such products are sold from our company. Please be aware that REMOVING the label and INSTALLING the printhead on your machine, you WON'T be entitled to our aftersales services including technical support, return and refund. Shipping apps.froo.com | Froo www.froo.com | Froo Cross Sell, Free Cross Sell, Cross promote, eBay Marketing, eBay listing Apps, eBay Apps, eBay Application Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
