Ortec Model 533 Dual Sum And Invert Amplifier

US $80.00

Tucson, Arizona, United States
Jan 29th

Open on mobile:
QR code

The ORTEC Model 533 Dual Sum and Invert Amplifier is a single-width NIM that incorporates two wideband unity-gain amplifiers. Amplifier A has four summing inputs and Amplifier B has two summing inputs. Both amplifiers invert the signals. If a non-inverting output is required, Amplifier A can be cascaded through Amplifier B to form the noninverting 4-input summing amplifier. By connecting A inputs in parallel and B inputs in parallel, the Model 533 can be used as a non-inverting amplifier with a gain of 1, 2, 3, 6, or 8. The wide dynamic range and wide bandwidth make the ORTEC Model 533 useful for summing and/or inverting any signals that fall within the dc to 7 MHz bandwidth, such as most NIM-standard linear or logic signals. A convenient oscilloscope monitor test point is located next to each of the six front-panel connectors. This Model 533 has only been used for a few hours on the test bench and is in wonderful original condition. Sums up to four linear inputs, inverting or noninverting Two independent amplifiers, each with a gain of –1 Wide bandwidth, dc to 7 MHz Wide dynamic range, 0 to ±10 V Excellent temperature stability Specifications PERFORMANCE VOLTAGE GAIN –1 for each input; tolerances ±2%. BANDWIDTH Dc to 7 MHz (tr =50 ns). INTEGRAL NONLINEARITY <±0.05%. TEMPERATURE INSTABILITY Gain <±0.005%/°C. Output DC Level <±50 µV/°C. INPUTS Four identical inputs for Amplifier A and two for Amplifier B; each accepts 0 to 10 V rated span, 12 V maximum, positive or negative, unipolar or bipolar; Zin ~666 Ohms, dc-coupled; Inputs A1, A2, B1, and B2 on front panel, Inputs A3 and A4 on rear panel; all BNC connectors. OUTPUTS One output for each Amplifier, A and B, completely independent of each other; range 0 to ±10 V linear; Zo ~ 0.1 Ohms Outputs A and B on front panel; BNC connectors. ELECTRICAL AND MECHANICAL POWER REQUIRED +24 V, 65 mA; –24 V, 65 mA. WEIGHT Net 0.9 kg (2 lb). Shipping 2.2 kg (5 lb). DIMENSIONS Standard single-width NIM .13 cm (1.35 X 8.714 in.) per DOE/ER-0457T.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	ORTEC
Country/Region of Manufacture	United States
Model	533
