Ov7725 Camera Module 640x480 Display Active Sccb Compatible I2c High Sensitivity

US $21.98

shenzhen, China
Jun 9th

Open on mobile:
QR code

OV7725 Camera Module 640x480 Display Active SCCB Compatible I2C High sensitivity Description OV7725 Camera Module 640x480 Display Active SCCB Compatible I2C Photographic array 640X480 IO voltage of 2.5V to 3.0V (internal LDO for nuclear power 1.8V) Power work 120mW/65fpsVGAYUV Sleep <20μA Operating temperature -20*C to 70*C Stable operation 0*C to 50 C Output format (8-10 bit)? YUV/YCbCr4: 2:2 RGB565/555/444 GRB4: 2:2 Raw RGB Data Optical size of 1 / 4 " 25 ° field of view The maximum rate of 60fps VGA Chen Sensitivity 3V / (Lux-sec) 50 dB SNR 60 dB dynamic range View Mode Progressive E-1 line to 510 line exposure 6.0μm x 6.0μm pixel size Dark Current 40mV/s at 60*C VCC ----- input supply voltage (recommended 3.3,5 V can also be, but is not recommended) GDN ----- ground point SIO_C --- SCCB interface control clock (Note: some of the low-level microcontroller needs pull-up control, and the I2C interface similar) SIO_D --- SCCB interface serial data input (output) end (Note: some of the low-level microcontroller needs pull-up control, and the I2C interface similar) VSYNC --- frame synchronizing signal (output signal) HREF ---- line synchronizing signal (output signal) The PCLK ---- pixel clock (output signals) D0-D7 --- data port (output signal) RESTE --- reset port (normal use pulled) PWDN ---- power selection mode (normal use pull down) OV7670 image sensor, small size, low operating voltage, and provides all the features of the single-chip VGA camera and image processor. SCCB bus control, you can output the entire frame, sub-sampled, take the window way affect data resolution 8. VGA image of the product is up to 30 frames / sec. Users can fully control the image quality, data format and transmission mode. The process of image processing functions including gamma curves, white balance, saturation, chroma, and so can be programmed through the SCCB interface. High sensitivity for low-light applications Low voltage suitable for embedded applications standard SCCB interface compatible with I2C interface RawRGB RGB (GRB4: 2:2, RGB565/555/444), YUV (4:2:2) and YCbCr (4:2:2) output format Support VGA, CIF, and from CIF to 40x30 of various sizes VarioPixel subsampling automatically affect the control functions include: automatic exposure control, automatic gain control, automatic white balance, automatic eliminate light stripes, automatic black level calibration image quality control including color saturation, hue, gamma, sharpness ANTI_BLOOM ISP has to eliminate noise and dead pixel compensation function support for image scaling The lens is the loss of light compensation 50/60Hz automatic detection saturation automatically adjust (UV adjustment) edge enhancement automatically adjust Noise Reduction automatically adjust Payment We accept PayPal payment ONLY. Delivery details 1) All items will be shipped to you Paypal address.please update your latest address when you check out,and please make sure to provide us with correct,precise,and detailed shipping Address. 2) Most of the items will be shipped via HongKong Airmail/Singapore Airmail Note:We will ship your items out via Singapore Post with a tracking number for free if your purchase exceeds $30.If not,and you still need a tracking code,please contact us when you place an order.For countries that are a little far away,especially South America,it is suggest that you add a tracking number for your order,in case of losing parcels. 3) TAX:We'll do our best to assist you to clear the goods,and the tax depends on each country's custom. 4) If you don't receive items over 30 busuness days,please feel to contact with us. 5) Below shipping time for your reference. (Since it is really busy season now,the post office gets so many packages to deal with every day,your parcel may be delayed for a few days.Hope you can understand and be patiet.) Returns 1. No-Question-Asked Refund! If for some reason you're not satisfied with our service or product quality,please contact us within 3 days after you get the package, you can return the products to us in origunal package and we will refund your money after we get the package!(Shipping cost is NOT refundable and you should responsible for the return shipping) 2. No-Question-Asked Replacement! Although all packages are packed professionally, few item(less than 0.1%) might be damaged during the shipping, You are welcome to contact us within 3 days after you receive your package about replacement. 3.Repair Some items migth be broken caused by improper use, we are always happy to offer any helpful repair service.Of course, you can send the broken items back to us and we will help you resolve the situation and charge reasonable repair fees.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Country/Region of Manufacture	china
MPN	Does not apply
UPC	Does not apply
