Pace Tf-2000 Bga/csp Reflow Rework System 2000p/2000b Base +2000r Pre-heater

US $4,995.00

San Diego, California, United States
Jan 31st

Open on mobile:
QR code

PACE TF-2000 BGA/CSP Reflow Rework System 2000P/2000B Base +2000R Pre-Heater We gladly ship to most countries! Email us for a Quote PACE TF-2000 BGA/CSP Solder Rework System 2000P/2000B/2000R Pace TF-2000 BGA / CSP Rework System The TF 2000 delivers unparalleled programmability and process control to ensure accurate placement and installation. Profiles are programmed through the PC software or by using the integral key pad. The unit is self-contained, eliminating the need for external air supply or vacuum connections. The 1000 watt heater, with closed loop temperature control, coupled with a unique nozzle design ensures uniform temperature distribution. Creating the perfect profile is easy with real time adjustment of profile parameters. PC base profile management ensures process consistency when multiple units are used. TF2000 Features & capabilities include: Self-Contained Blower and Vacuum Pumps Status LED's Automatic Cooling Fan Store and recall up to 40 profiles at the touch of a button, or an infinite number of profiles using the PC Fully programmable using PC software or LCD display and key pad 2 pre-defined profiles for use as baselines when developing profiles Semi-automated, motorized reflow head Integrated cooling fan with auto on/off 2 Thermo-Couple sensor inputs ensure successful profile development Placing a wide variety of component types and sizes: PBGAs, , CSPs, Flip Chips, or any SMD Effectively pre-heating multi-layer and large boards Easy relocation for facilities that need a portable rework system Documenting quality assurance and process control TF 2000 Base/Pre-Heater The TF 2000 Board Holder with integrated Pre-Heater holds PCBs securely while delivering heat efficiently and effectively. The IR Pre-Heater ensures process integrity by delivering heat evenly, time after time. Fully adjustable board supports are also available. TF 2000 Base/Pre-Heater Features Techno-Glide Board Platform for smooth operation Fully adjustable, precision, spring loaded Board Holder Adjustable end-stops for repeatable operations Integrated IR Pre-Heater for effective pre-heating 400 watt Pre-Heater with closed loop temperature control TF 2000 Placement Station Incorporating a High Resolution Vision Overlay System (VOS), the TF 2000 offers the most advanced optics available today. The placement station can be used to accurately position any Array Package up to 50mm (2") square or any SMD. The unique design does not require routine calibration, eliminating costly down time and operator frustration. The VOS can be viewed and operated through the PC software or through a video monitor and front panel controls. Placement Station Features Techno-Glide Board Platform for smooth operation Fully adjustable, precision, spring loaded Board Holder Adjustable end-stops for repeatable operations Integrated IR Pre-Heater for effective pre-heating 400 watt Pre-Heater with closed loop temperature control System Description The PACE TF-2000 BGA / CSP Rework System is comprised of three self-contained stations: the reflow station, the placement station and the base / pre-heater station. Each individual station is lightweight and compact, allowing for easy set-up and portability. Up to 40 reflow profiles can be stored by the TF 2000. Save profiles can be recalled at the touch of a button and are displayed on the LCD display panel. Product Family: TF-2000, TF 2000, TF2000, TF-2000R, TF 2000R, TF2000R, TF-2000P, TF 2000P, TF2000P, TF-2000B, TF 2000B, TF2000B, TF-2000BE, TF 2000BE, TF2000BE, TF-2000BL, TF 2000BL, TF2000BL, TF-2000BLE, TF 2000BLE, TF2000BLE Specifications Heater: (top side) Hot Air, 1000 Watt Pre-Heater: ** Light IR, 400 Watt (200 Watt x 2), 220mm x 155mm (8.6" x 6.1") PCB Size: ** 360mm x 430mm (14" x 17") Standard, 430mm x 500mm (19.5" x 17") max with optional extended rails Air Flow: Self Contained, Manual Adjust, 30 SLPM max Resolution on Optics Adjustment: 0.52mm (0.02") per rotation Positioning Accuracy: (Z travel) 25 (0.001") Vacuum: 450mm Hg Power Supply: 100-120VAC, 60Hz or 230VAC, 50Hz Power Consumption: 1600 Watts (max) Optics: High Resolution, Vision Overlay System Video Out: S Video or B/C Temperature Range: Pre-Heater 100 Top Heater 100 Dimensions: 491mm H x 516mm W x 517mm D (19.4" H x 20.3" W x 20.3" D) Net Weight: 115VAC Model 125 pounds (57 Kg), 230VAC Model 145 pounds (66 Kg) Item is in fair condition with some rust on the metal rods. unit turns on, heats up, displays the settings on the screen and the vacuum turns on. Don't forget to place your bid. By bidding on this auction you agree to the following terms: Shipping Terms: Buyer pays all shipping costs. Let us know if there is an issue with the shipping costs, as they are automatically calculated by ebay. Shipments made to California must include 8.00% sales tax unless we are provided with a valid resale certificate. Payment Terms: Payment is to be made by PayPal Please contact us if you have any questions Payment is to be received within ten days of close of auction. Should payment not be received within ten days the item will be re-listed and high bidder will forfeit. No personal checks will be accepted. International Terms: (These terms only apply to international shipments.) Buyer is responsible for all brokerage, customs, and or duty charges. Not all items are available for international shipment due to import/export regulations. In the event that we are unable to ship to buyers country, buyer will receive a full refund. Payment must be made in US Dollars. Money must be drawn against a US bank. Warranty Terms: The 14-day return period begins the day of receipt. What you see in the picture(s) is what you get nothing more nothing less. Test results of item(s) in auction are described to the best of our ability in the ad. The results of all tests that are performed are disclosed in the ad. The maximum liability of Betterstudiogear is the high bid of the auction. Return Terms: Returns are allowed within 14 days we employ security features on our items and record all serial numbers to ensure we receive the same item back. Medical Terms: The following terms apply to any and all medical items or any item offered for sale in any medical category or any item that eBay deems these terms are applicable to: The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If so, you may not on this item unless you are an authorized purchaser. If the item is subject to FDA regulation, I will verify your status as an authorized purchaser of this item before shipping of the item. The buyer will not hold the seller, eBay or the item's manufacturer responsible for the appropriate or inappropriate use of this device either by the user or a third party. Once purchased, it is the sole responsibility of the purchaser to assume any and all liability from the use of this device. Please note before bidding that any medical equipment purchased should be completely tested by a qualified biomedical technician prior to being put into service Dan Rydell in San Diego, CA, USA Phone: 619-519-0869 Online Business name: Betterstudiogear If any provision of this Auction Contract is held unenforceable, All remaining provisions of this Contract shall remain in full force and effect. Copyright 2014 Betterstudiogear - All Rights Reserved. Auction Wizard 2000 - The Complete Auction Management Software Solution

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“fairly good condition, turns on.”
