Palmgren 9" X 20" Bench Engine Lathe

US $1,995.00

Naperville, Illinois, United States
Feb 24th

Open on mobile:
QR code

PALMGREN 9" x 20" BENCH ENGINE LATHE ------------------------------------------------------------------------------------------------------------------------------------------------------- PALMGREN 9" x 20" BENCH ENGINE LATHE INVENTORY # 6489 MODEL: 9" x 20" DESCRIPTION: PALMGREN'S 9" BENCH ENGINE LATHE DELIVERS THE PRECISION, POWER AND VERSATILITY TO HANDLE A WIDE RANGE OF TURNING OPERATIONS NORMALLY FOUND IN MUCH LARGER MACHINES THE BENCH LATHE IS THE RIGHT CHOICE FOR TURNING SMALL METAL PARTS AND IS USED IN PROTO TYPE SHOPS, TOOL ROOMS, FABRICATION SHOPS, MAINTENANCE SHOPS, JEWELRY MANUFACTURING AND BY HOME AND HOBBY MACHINISTS SPECIFICATIONS: CENTER HEIGHT: 4.92" DISTANCE BETWEEN CENTERS: 21.65" TURNING DIAMETER: 9.84" SWING OVER COMPOUND SLIDE: 5.91" MAXIMUM BED WIDTH: 5.31" SPINDLE SPEED: 125 - 2,000 RPM NUMBER OF STEPS: 6 SPINDLE TAPER: MT4 SPINDLE HOLE: 1.02" CHUCK SIZE: 4.92" TOP SLIDE TRAVEL: 2.76" COMPOUND SLIDE TRAVEL: 4.33" TAILSTOCK TAPER: MT2 TAILSTOCK SLEEVE TRAVEL: 2.56" LONGITUDINAL FEED: .002" - .012" PITCH: 56 - 8" TOOL HOLDER SEAT HEIGHT: 0.5" MOTOR: 1 HP / 115 V / 1 PH STANDARD FEATURES: MACHINE TOOL SPINDLE DUAL P5 TAPPER ROLLER BEARINGS ON SPINDLE PRISMATIC BED OF SOLID AGED CAST IRON - HARDENED TO HRO 42-52 FOR LONG LIFE FAST EASY FEED SPEED AND DIRECTION CHANGES WITH FRONT MOUNTED SELECTOR HANDLES FEED GEAR BOX IS CONSTRUCTED OF STEEL GEARS RUNNING IN AN OIL BATH FEED LEAD SCREW IS SUPPORTED AND RUNS ON TWO BEARINGS PRECISION MACHINED SLIDE WITH ADJUSTABLE HAND WHEELS WITH 0.002" / 0.001" SCALES TAILSTOCK WITH ADJUSTABLE PRECISION SCALE OF 0.02 MM / 0.001" 3-JAW LATHE CHUCK 4-WAY TOOL POST SAFETY LATHE CHUCK AND TOOL POST GUARDS CENTERS CHIP TRAY AND SPLASH GUARD MECHANICAL SPECIFICATIONS: WEIGHT: 276 LBS DIMENSIONS: 49" x 23" x 19" FOB FACTORY CHECK OUT OUR OTHER LATHES HERE CONTACTING NORMAN MACHINE TOOL, LTD: For immediate response to questions, please contact us at 1-800-394-4399 during business hours. (Weekdays, 9am - 5pm EST) If you contact us by email, or after business hours, we will answer your questions as soon as possible. NEW MACHINE NOTIFICATION TO PROSPECTIVE BUYERS: Norman Machine Tool, Inc strives to keep listings current for our customers. Manufacturer's specifications and availability are subject to change without notice. Stock photos are to be considered representations only and may show optional accessories, different models, or possible color differences from the actual machine being offered for sale. CONTACT US: Norman Machine Tool Group 1311 South Ponca St Baltimore, MD 21224 Phone: 800-394-4399 Fax 410-633-7737. Business Hours: Monday-Friday / 9 a.m. - 5 p.m. (Closed most Holidays - Call if not sure) RETURNS Returns will not be accepted without prior approval. If you need to make a return, please contact us before you ship the merchandise back so we can issue you a Return Merchandise Authorization (RMA) number. All items are sold with the best intentions and most complete description available. PLEASE ASK QUESTIONS BEFORE BIDDING!!! Buyer must pay for return shipping. RUN THREE PHASE MOTORS WITH SINGLE PHASE POWER Use a Phase-A-Matic Static or Rotary Phase Converter. Buy the best & buy Phase-A-Matic. Phase-A-Matic phase converters are proven to last for 20 to 30 years. You can run multiple three phase motors from just one phase converter, allowing you to run multiple three phase motors off single phase power! View Phase-A-Matic in our Phase Converter aisle of our eBay store! ............ DISCLAIMER: The information and pictures are believed to be accurate to the best of our knowledge, obtained from sources deemed reliable. However, we do not guarantee accuracy of information and cannot be responsible for any errors or omissions. An inspection should be made. The information on the web site should not be used for formal quotation. Price and information presented in the write ups on the web site are subject to change without notice. Please contact one of our sales representatives if you require more information or a current formal quotation. NORMAN MACHINE TOOL, LTD. CONDITIONS OF SALE: INSPECTION AND TEST EQUIPMENT Inspection & Test Equipment will be sold "AS IS" with a conditional return policy on a case by case basis. Please ask questions! The equipment's condition stated in the listing is accurate to the best of our knowledge. We do not specialize in these products and have no way of checking them beyond visual and some minor mechanical functions. We assume most of this equipment must be calibrated professionally. We feel the low prices we offer more than makes the equipment a great value! MDNA 30 DAY WARRANTY Every used machine offered (unless sold on an "as is" basis or brokered) bears a thirty day return privilege. In the event it is found mechanically unsatisfactory (excludes electrical*, as well as original manufacturer’s accuracies and tolerances), it may be returned within thirty (30) days of shipment, freight prepaid, provided it is in the same condition as when shipped from Norman Machine Tool, Ltd., for full refund of purchase price or repaired at the seller's sole discretion. All new machines that have been manufactured by others that have warranties, expressed or implied, are hereby expressly limited to the warranty of the original manufacturer of the goods. All implied warranties of merchantability and fitness for a particular purpose are hereby disclaimed and excluded from this agreement. Care is taken to give reliable descriptions but these are not guaranteed and prospective purchasers are advised to check vital details. We also reserve the right to correct any stenographic errors. All specifications and descriptions of said goods are approximate only. Seller makes no representation or warranty that said goods conform to any specification, description and condition or performance, it is the buyer's responsibility to inspect the goods and ascertain if the specifications, description, and condition of the goods conform to the buyer's requirements. Any warranty concerning said goods made by a third party is enforceable only against the third party and not the seller. Conforms to the mdna code of ethics. 30 Day MDNA Warranty applies to items sold at the advertised price.This warranty does not apply to Best Offers without prior agreement, or items sold As-Is. PAYMENT DETAILS: Norman Machine Tool Ltd. gladly accepts PayPal, Visa, Master Card, American Express and Discover. We can run your credit card at our warehouse, or if your prefer, even without an account, you can sign into PayPal as a guest and use your credit card. Local pickups at our warehouse in Baltimore, MD are required to pay 6% Maryland state taxes to abide by Maryland state laws. SHIPPING DETAILS: When payment has cleared, large items that must be shipped via truck will ship as soon as the truck can be secured, usually within 10 business days. Special preparation, such as crating, will delay shipment and will be available at additional cost. We can secure your equipment on a pallet, starting at $50 and varying based on the equipment size, weight, and materials needed. The buyer pays for all shipping. All items need to be paid for within 72 hours of auction end. Go Back to Our Store Homepage Powered by SixBit's eCommerce Solution On Nov-21-14 at 21:32:32 PST, seller added the following information: Sellers: Delight buyers. Get your own map of past buyers.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Palmgren
Model	9" x 20"
