Panasonic K30 3v 30000rpm Ab Phase Holzer Velocimetry Micro Motor Reducer Wheel

US $3.69

  • Guandong, China
  • Jan 29th
Open on mobile:
QR code
Panasonic K30 3V 30000rpm AB phase Holzer velocimetry micro motor reducer Wheel Coding speed motor + Wheel. The goal is to make micro (deceleration motor can be fixed on a PCB desktop intelligent car), of course also not exclude other application. Panasonic K30 motor speed (30000 RPM) +AB motor phase linear Holzer sensor + miniature strong magnetic  The main parameters are as follows: 1.3V 30000rpm, the gear is also embedded with a magnet, so high speed machining accuracy need very precise, otherwise the magnet be split. 2 with dual Micro Linear Holzer sensor, not only can judge the direction of rotation, with the precision of the circuit can also determine the absolute position of the motor shaft (level Holzer sensor determines the position of the rotor) The 3 coil resistance of 6 ohm Applications: 1. The motor idling resistance is small, with the gear can be used as other systems of AB encoder, linear Holzer sensor flexible application, with the circuit can improve coding resolution (turn can output multiple pulses), according to the output of Holzer sensor voltage can determine the position of the rotor. If the judge point position of use. 2. With a gear, with the appropriate module gear reducer output power. As with the AB phase encoding speed motor.    Sensor test circuit: (tested only A phase) 1, the 3 foot 20mA input current, 2,4 pin 9, pin 10 connected oscilloscope, 3V voltage to the motor rotation, 2, 4 feet from the voltage waveform, the P-P voltage is about 500mv, the linear Holzer element is very sensitive, high output voltage amplitude. Waveform and voltage of rotor position is sine relationship is very beautiful.   Package Including: 1. Panasonic high-speed K30 motor, with AB phase linear Holzer sensor.x1 2. Miniature tooth box (coil spring back). x1  3. Tire. (including rubber ring, diameter 30mm) x1
