Parker Acroloop Pc-acr8010-03 1-8 Axis Pc-bus Or Standalone Motion Controller

US $1700

Richardson, Texas, United States
Jun 23rd

Open on mobile:
QR code

Parker Acroloop PC-ACR8010-03 1-8 Axis PC-Bus or Standalone Motion Controller with PC-ACRIO-02 | Compatible with ACH6800 The Acroloop controllers are used in a wide variety of single and multi-axis applications. The applications for the Acroloop controller family are virtually unlimited, due to the flexible design. The main purpose of the controllers is to provide a flexible, yet easy to program environment, while insuring the motion profiles and digital I/O tasks are executed in real-time, independent of any operating system or operating station. The Acroloop controllers are 32/64 bit floating-point Multi-Tasking DSP-based motion controllers. The Acroloop controller family is ideal for applications requiring a high degree of processing power and fast performance - eliminating the need or burden for a host processor. The controllers can perform independent or coordinated axis moves including circular, linear, sinusoidal, elliptical, helical, and spherical interpolation in any combination of up to 4 and 8 axis. In addition, the user can define up to 8 coordinate systems for up to 24 programs (16 motion and 8 PLC programs). In typical applications, the pre-emptive multi-tasker will execute motion profiles and execute a ladder logic PLC simultaneously. Features: • Texas Instruments TMS320C3X Series - 32/64 bit Floating Point DSP • Pre-emptive multi-tasker for up to 16 simultaneous motion programs • Pre-emptive multi-tasker for up to 8 simultaneous PLC programs • Handles 1-2, 1-4, or 1-8 axis applications (“cascade-able” for additional axis) • 32 bit Floating Point DSP @ 27/40/50/60 MHz • 64 optically-isolated Digital I/O on ACR8000/ACR8010, expandable to 320 digital I/O • 32 optically-isolated Digital I/O on ACR1200/ACR2000, expandable to 288 digital I/O • 48 TTL Opto-22 Compatible Digital I/O on ACR1500 • On-board 24VDC @ 1A Watchdog Relay (SPDT) for ACR1200/ACR2000/ACR8000/ACR8010 • On-board Open-Collector Normally-Open and Normally-Closed Watchdog Outputs @ 30mA for ACR1500 • EPROM’s for permanent firmware and program storage • Flash Memory for permanent program storage • Zero Wait State System RAM • 1 Megabyte RAM memory on ACR2000 and ACR8010 • 256Kbytes RAM memory on ACR1200 and ACR1500 • 128Kbytes RAM memory on ACR8000 • Hardware Capture and Compare registers • 8 User Programmable Status LED’s on ACR8000 and ACR8010 • Handles both servo and stepper applications • Optional 12-Bit or 16-Bit A/D (analog-digital) input boards for ACR1200/ACR1500/ACR8000/ACR8010 • Optional 12-Bit On-board A/D (analog-digital) input for ACR2000 Markings found on unit: ACR I/O AD-2 15500B0088 15400L207 PC-ACRIO-02 SP1919-014 8010 std-2 MCC '00 06 We recognize that an ARTICLE may have numerous different configurations. We want you to make an informed decision therefore, we make the effort to give you as much information as resources permit. Some markings such as serial numbers and/or other identifying marks may vary. Please let us know if there is a particular device date code or marking that works best for you. We will continue to work hard to get you what you need. That is our pledge. Please let's Make It a "Win-Win". 100% Satisfaction Guaranteed. Get the item you ordered or get your money back. Covers your purchase price and original shipping. Thanks for shopping.
