Part#px3-1731u

US $600.00

Fremont, California, United States
Jul 4th

Open on mobile:
QR code

Rack Power Distribution Units (PDUs) Features Securelock Removable Controller Energy Metering Voltage (V), Current (A), Active Power (kW), Real Power (kVA), Energy (kWh), Power Factor Metering Accuracy ISO/IEC 62053-21 1% Remote Outlet Switching No Metering per input line Yes for all models Metering per Branch Circuit Breaker Yes Environmental Sensor Ready Yes Compatible Sensors Temperature, Humidity, Air Flow, Differential Pressure, Water Leak, and Contact Closure. View all sensors. Cascading Yes, Max 16 PDUs can be daisy chained using a USB connection. Note: Firmware version 3.3.10 or above is required. Networking (10/100/1000 Base T) Ethernet, Secondary redundant (10/100 Base T) Ethernet. Optional WiFi (802.11 a/b/g/n). Onboard Display Color, matrix LCD display : Voltage, current, or active power (per line or per breaker); Alarms; Configuration information (name, ratings, IP / Networking information). Auto-flip orientation Specifications Input Input Plug NEMA L22-30P (4P5W) Nominal Voltage 415V Maximum Input Current 30A Rated Input Current 24A Power Capacity 17.3kVA Cord Length 3m Output Nominal Voltage 240V Receptacles (Output Connections) (24) IEC320 C13 (12) IEC320 C19 Overload Protection (6) Airpax LELBX1-20 Physical Dimensions (WxDxH) 2.1in x 2.2in x 70.1in; 52mm x 55mm x 1780mm Unit Weight TBD Shipping Weight TBD Shipping Dimensions 280mm x 115mm x 2055mm Mounting Tool-less Button Mount Environmental Operating Temperature/Environment 60 C Operating Relative Humidity 85% Operating Elevation 0-6000ft Conformance Regulatory Approvals UL Warranty Standard 2 years manufacturer warranty Tender Text/Bid Submittal Text Monitored rack power distribution unit (0U [vertical], 17.3kVA, 36 outlets). INPUT: 415v (3-phase WYE), 30a - NEMA L22-30P plug (4P5W); OUTPUT: 24@ C13, 12@ C19 outlets; on 6@ 1-pole, 20a Overcurrent Protectors; FEATURES: Billing-Grade (+/- 1%) Energy Metering [kW, kVA, V, A, Power Factor] - per inlet, per breaker/fuse; Remote network monitoring via HTML, JSON-RPC, SSH, Telnet, MODBUS/TCP, and SNMPv3. Onboard embedded processor with minimum 536MHz clock speed, 16MB SPI Flash, and 64MB DDR2 RAM. Cascading upto 16 PDU's using single Ethernet or USB connection. Environmental monitoring [temp/humidity] capable – up to 32 sensors. Individual outlet numbers labeled on chassis. Automated deployment via TFTP, DHCP, SSH(CLI), or USB Flash Drives. WiFi Capable. USB Webcam Capable. iPad/iPhone/Android App. Dual 10/100/1000 Ethernet port. Breaker metering and alarming (0V detection). Max Dimensions 52mm x 55mm x 1780mm (2.1in x 2.2in x 70.1in). Max Weight TBD. Maximum ambient temperature 60C at full load. Vendor: Raritan; Part Number: PX3-1731U Electrical (One Line) Diagram

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Number of Outputs	36
Brand	Raritan
MPN	PX3-1731U
UPC	Does not apply
